Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6450*2490*3940mm
-
Machine Weight:
-
10050 kg
-
Bucket capacity:
-
1.2CBM, 1.2cbm
-
Marketing Type:
-
New Product 2023
-
Rated Power:
-
75kw/2400rpm
-
Rated Load:
-
2500kg
-
Dumping Height:
-
3050mm
-
Backhoe capacity:
-
0.3cbm
-
Tyre:
-
16.9-28
-
Overall dimensions:
-
6450*2490*3940mm
-
Operating weight:
-
10050kg
-
Model:
-
TA388H
-
color:
-
Customer's Requiement
Quick Details
-
Engine Brand:
-
YUCHAI
-
Power:
-
75 KW
-
Brand Name:
-
TAVOL
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6450*2490*3940mm
-
Machine Weight:
-
10050 kg
-
Bucket capacity:
-
1.2CBM, 1.2cbm
-
Marketing Type:
-
New Product 2023
-
Rated Power:
-
75kw/2400rpm
-
Rated Load:
-
2500kg
-
Dumping Height:
-
3050mm
-
Backhoe capacity:
-
0.3cbm
-
Tyre:
-
16.9-28
-
Overall dimensions:
-
6450*2490*3940mm
-
Operating weight:
-
10050kg
-
Model:
-
TA388H
-
color:
-
Customer's Requiement
Product Advantage
Features:
*YUCHAI YC4A105Z-T20 75kW engine *ROPS/FOPS cabin with air conditioning
*Front and rear mechanical operating handles
*Front tire size: 16.9-28, rear tire size: 16.9-28
*One set auxiliary hydraulic pipes & hoses
is installed on backhoe arm
*Steer mode: 4-wheel steer, 2-wheel steer, crab steer mode
*Backhoe arm with function of hydraulic
side shifting
side shifting
*H type supporting legs.
Optional:
*Carraro transmission and axle imported from Italy;
*Pilot control with joystick for hydraulic system;
*Backup camera;
*Pilot control with joystick for hydraulic system;
*Backup camera;
*Front Loading End:6 in 1 bucket;
*Front Loading End:quick coupler;
*Front loading end: Type A wooden fork, etc. *Rear digging end: breaking hammer, wooden fork, etc.
*Front Loading End:quick coupler;
*Front loading end: Type A wooden fork, etc. *Rear digging end: breaking hammer, wooden fork, etc.
*Rear excavation end: auger, telescopic boom, etc.
*etc.
Product Specifications
|
Model
|
TA388H
|
|
|
|
General specification
|
Overall Operating Weight
|
10050KG
|
|
|
2
|
Overall Dimentions
|
6450mm*2490mm*3940mm
|
|
|
3
|
Wheel Base
|
2335mm
|
|
|
|
Wheel tread
|
2139mm
|
|
|
5
|
Bucket Capacity
|
1.2m3
|
|
|
6
|
Loading Lifting Capacity
|
2500KG
|
|
|
|
Bucket Dumping Height
|
3050mm
|
|
|
|
Max. Digging Depth
|
3820mm
|
|
|
|
Backhoe Capacity
|
0.3 m3
|
|
|
Engine information
|
Brand
|
Yuchai, Weichai, Cummins
|
|
|
|
Model
|
YC4A105Z-T20
|
|
|
|
Rated Power(kw)
|
75KW
|
|
|
|
Engine speed(r/m)
|
2200
|
|
|
|
Max. Torque
|
400N.M
|
|
|
Transmission system information
|
Torque Converter Model
|
315
|
|
|
|
Gear Shifting
|
F4R4
|
|
|
|
Gearbox Model
|
28
|
|
|
|
Tyres Model
|
16.9-28
|
|
|
Working control system
|
Working Control Type
|
Mechanical control
|
|
|
Hydraulic system information
|
Working pump displacement
|
63ml/r
|
|
|
|
Working pump pressure
|
20Mpa
|
|
|
|
Diverter model
|
BZZ5-250
|
|
Product Detailed Information
Luxury Instrument Board
Spring Armrest Seat
Mechanical Control
Backhoe Bucket
Breaking Hammer
Auger
Production Line
We adopt strict production line rules to ensure high quality for our customers.
Product Packaging
Optional
Bulk cargo/ RO-RO
/ Full containers;
1 unit naked within 1 x 40HQ container.
Our Service
We have a professional after-sales team
In technical support and after-sales service, we always adhere to our company's consistent quality management policy and the service principle of
"Making global customers proud of choosing the Tavol brand"
to ensure that we provide customers with complete and thoughtful technical support and after-sales service. Our company's service purpose is always to provide customers with professional, standardized and diversified services.
