Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Damyo
-
Dimension(L*W*H):
-
67*49*58cm
-
Weight:
-
76
-
Rated power/speed:
-
15kw/3000rpm 16.5kw/3600rpm
-
Product name:
-
Diesel Engine RJ2V92
-
Type:
-
Two Cylinder,V-twin,four stroke,Air-cooled
-
Bore*Stroke:
-
2-92*75mm
-
Compression Ratio:
-
20:01
-
Rated Power:
-
20.4HP 22.4HP
-
Rated Speed:
-
3000rpm/3600rpm
-
HS Code:
-
8408909119
-
Lubricating system:
-
Pressure splashed
-
Rotation direction:
-
Counterclockwise (face to the output axle)
Quick Details
-
Displacement:
-
997cc, 997cc 997ml
-
Emission Standard:
-
Other
-
Power:
-
16500W, 18200W
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Damyo
-
Dimension(L*W*H):
-
67*49*58cm
-
Weight:
-
76
-
Rated power/speed:
-
15kw/3000rpm 16.5kw/3600rpm
-
Product name:
-
Diesel Engine RJ2V92
-
Type:
-
Two Cylinder,V-twin,four stroke,Air-cooled
-
Bore*Stroke:
-
2-92*75mm
-
Compression Ratio:
-
20:01
-
Rated Power:
-
20.4HP 22.4HP
-
Rated Speed:
-
3000rpm/3600rpm
-
HS Code:
-
8408909119
-
Lubricating system:
-
Pressure splashed
-
Rotation direction:
-
Counterclockwise (face to the output axle)
Product Features:
-----Easy and quick start,Strong Power
-----Low fuel consumpation
-----Miniature fuel injection system
-----Mature production technology
-----Support high intensity use
-----Wide application area
-----Low fuel consumpation
-----Miniature fuel injection system
-----Mature production technology
-----Support high intensity use
-----Wide application area
Application of diesel engines
-----Agricultural machines:tillers,harvesters,ditchers,branch chipper,rice milling machines,water pumps etc
-----Construction machines:plate compactors,road rollers,road cutting machines,generators etc
-----Transporation machines:walking tractors,boats etc
-----Construction machines:plate compactors,road rollers,road cutting machines,generators etc
-----Transporation machines:walking tractors,boats etc
|
Model
|
RJ2v92
|
|
Type
|
Two Cylinder,V-twin,four stroke,air-cooled
|
|
BoreXStroke(mm)
|
2-92*75
|
|
Displacement(ml)
|
997
|
|
Compression Ratio
|
20:1
|
|
Rated Power(KW/rpm)
|
15/3000 16.5/3600
|
|
Max Power(KW/rpm)
|
16.5/3000 18.2/3600
|
|
Rated Power(HP/rpm)
|
20.4/3000 22.4/3600
|
|
Max Torque(N.m/r/min)
|
59/2400
|
|
Rated Speed
|
3000/3600
|
|
Starting System
|
0#(summer)--10#(winter)-35#(chillness) diesel
|
|
Fuelconsumption(g/kW.h)
|
≤245
|
|
Lube oil cpacity(L)
|
3.8
|
|
Noise at 7m(dB)
|
≤86
|
|
Starting way
|
Electric Starter
|
