Quick Details
-
Connector type:
-
Sma 905 Quartz
-
Fiber Type:
-
G652D/G657A1/G657A2/G657B3
-
Certification:
-
CE/ROHS/ISO9001
-
Jacket:
-
PVC LSZH LSOH PE HDPE
-
Application:
-
Telecom Comunication
-
Packing:
-
Plastic Drum
-
Polishing Manner:
-
APC PC UPC
-
Cable Type:
-
Simplex Duxplex Fiber Patch Cord
-
Package:
-
2km/roll
Quick Details
-
Brand Name:
-
Fiber future
-
Model Number:
-
fc-sma905
-
Place of Origin:
-
Hunan, China
-
Connector type:
-
Sma 905 Quartz
-
Fiber Type:
-
G652D/G657A1/G657A2/G657B3
-
Certification:
-
CE/ROHS/ISO9001
-
Jacket:
-
PVC LSZH LSOH PE HDPE
-
Application:
-
Telecom Comunication
-
Packing:
-
Plastic Drum
-
Polishing Manner:
-
APC PC UPC
-
Cable Type:
-
Simplex Duxplex Fiber Patch Cord
-
Package:
-
2km/roll
Product Description
Specification
|
Connector Type
|
LC UPC to LC UPC (LC SC ST FC)
|
Fiber Grade
|
G.657.A1 (Compatible with G.652.D)
|
|
Fiber Mode
|
OS2 9/125μm
|
Wavelength
|
1310/1550nm
|
|
Insertion Loss
|
≤0.3dB
|
Return Loss
|
≥50dB
|
|
Min. Bend Radius
(Fiber Core) |
10mm
|
Min. Bend Radius (Fiber Cable)
|
10/5D (Dynamic/Static)
|
|
Attenuation at 1310 nm
|
0.36 dB/km
|
Attenuation at 1550 nm
|
0.22 dB/km
|
|
Fiber Count
|
Simplex
|
Cable Diameter
|
2.0mm
|
|
Cable Jacket
|
PVC (Riser/OFNR)
|
Polarity
|
A (Tx) to B (Rx)
|
|
Operating Temperature
|
-20 to 70°C (-4 to 158℉)
|
Storage Temperature
|
Storage Temperature
|
*Standard length:1000m;Other length availabe
*The above is just a suggestion for container loading, please consult our sales department for the specific quantity
*The above is just a suggestion for container loading, please consult our sales department for the specific quantity
Packing & Delivery
Fast Delivery: 3 Workdays
For Sample,
10 Workdays
For Bulk Order
