Quick Details
-
Model Number:
-
W-208/W-18
-
Dimension:
-
550*265*360mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
400W RMS
-
Format:
-
two-way line array system
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm 8 ohm(W-18/W-18P)
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Power amp:
-
600W/8ohm (W-208P)900W/8ohm(W-18P)
-
Amplifier type:
-
Switching power amp, class D circuit
-
Max-S.P.L:
-
LF 122dB(PEAK/1M) HF 128dB(PEAK/1M)130dB(PEAK/1M)(W-18/W-18P)
-
Output section:
-
2-channel
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-208/W-18
-
Dimension:
-
550*265*360mm
-
Storage:
-
Other
-
SNR:
-
Other
-
Output Power:
-
400W RMS
-
Format:
-
two-way line array system
-
Type:
-
line array system
-
Frequency Response:
-
70Hz-20KHz±3dB
-
Color:
-
Black
-
Nominal impedance:
-
16 ohm 8 ohm(W-18/W-18P)
-
Coverage:
-
110°H*10°V
-
Finsh:
-
Textured high-density polyurethane coating
-
Power amp:
-
600W/8ohm (W-208P)900W/8ohm(W-18P)
-
Amplifier type:
-
Switching power amp, class D circuit
-
Max-S.P.L:
-
LF 122dB(PEAK/1M) HF 128dB(PEAK/1M)130dB(PEAK/1M)(W-18/W-18P)
-
Output section:
-
2-channel
Product Description
|
Model
|
W-208 & W-208P(Active)
W-18 & W-18P(Active) |
|
Type
|
Two-way line array system
Sub-bass system(W-18 & W-18P) |
|
Frequency Response
|
70Hz-20KHz±3dB
40Hz-500Hz±3dB(W-18 & W-18P)
|
|
Power handling
|
LF 400W(RMS)1600W(PEAK)
HF 90W(RMS)360W(PEAK) 800W(RMS)3200W(PEAK)(W-18 & W-18P) |
|
Sensitivity
|
LF 100dB(1W@1M)
HF 101dB(1W@1M) 101dB(1W/1M)(W-18 & W-18P) |
|
Max SPL
|
LF 125dB(PEAK/1M)
HF 128dB(PEAK/1M) 129dB(1W/1M)(W-18 & W-18P) |
|
Drivers
|
LF 2×8"(210mm) neodymium woofer 65mm (2.5in)coil
HF 1×2.5" neodymium compression driver with 65mm titanium diaphragm
1×18"(460mm) woofer 100mm(4in)coil(W-18 & W-18P)
|
|
Nominal impedance
|
16 ohm
8 ohm(W-18 & W-18P) |
|
Coverage
|
110°H×10°V
|
|
Connectors
|
2×NL4MP speakon
|
|
Enclosure
|
Birch Plywood
|
|
Dimensions
|
550×265×360mm(W×H×D)
550×650×780mm(W×H×D)(W-18 & W-18P)
|
|
Packing Dimensions
|
430×630×360mm(W×H×D)/0.1cbm
720×860×620mm(W×H×D)/0.38cbm(W-18 & W-18P) |
|
Net weight
|
22kg (W-208)
60kg(W-18)/66.5kg(W-18P) |
|
Gross weight
|
25kg(W-208)
65kg(W-18)/71.5kg(W-18P) |
