Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Solarway/OEM
-
Model Number:
-
NPS1500
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
41*25.2*10.1cm
-
Weight:
-
4.88kg
-
Output Waveform:
-
Pure Sine Wave
-
Continuous Power:
-
1500W
-
Peak Power:
-
3000W
-
USB output USB:
-
5V 2.1A
-
Built in battery charger:
-
3 stage, 10A
-
UPS function:
-
Transfer time less 10ms
-
Protection Function:
-
Bat.low alarm, Bat.low shutdown, over voltage, polarity reverse ,etc
-
Certificate:
-
CE ROHS E8
Quick Details
-
Output Current:
-
According to load
-
Network:
-
other
-
Customized support:
-
other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Solarway/OEM
-
Model Number:
-
NPS1500
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
41*25.2*10.1cm
-
Weight:
-
4.88kg
-
Output Waveform:
-
Pure Sine Wave
-
Continuous Power:
-
1500W
-
Peak Power:
-
3000W
-
USB output USB:
-
5V 2.1A
-
Built in battery charger:
-
3 stage, 10A
-
UPS function:
-
Transfer time less 10ms
-
Protection Function:
-
Bat.low alarm, Bat.low shutdown, over voltage, polarity reverse ,etc
-
Certificate:
-
CE ROHS E8
Recommend Products
Products Description
Solarway is a Sino-german Joint venture which is a professional off-grid power inverter manufacturer in Jiaxing city ,near to Shanghai.
We are mainly engaged in high-tech DC TO AC inverter, solar panel/DC TO DC converter, MPPT/PWM and other solar system accessories, OEM and ODM service are available.
We have R & D Center and After-sales Service Center in Beijing, China and Leipzig, Germany.
We are mainly engaged in high-tech DC TO AC inverter, solar panel/DC TO DC converter, MPPT/PWM and other solar system accessories, OEM and ODM service are available.
We have R & D Center and After-sales Service Center in Beijing, China and Leipzig, Germany.
|
Parameter introduction
|
|
|
|
Model
|
NPS1500
|
|
|
Inverter part
|
|
|
|
AC voltage
|
100-120v/220-240v
|
|
|
Rated power
|
1500w
|
|
|
Surge power
|
3000w
|
|
|
Wave form
|
pure sine wave(THD<3%)
|
|
|
Frequency
|
50/60hZ±3Hz
|
|
|
AC regulation
|
±5% or 10%
|
|
|
DC voltage
|
12v or 24v
|
|
|
Charger part
|
|
|
|
Max charging current
|
15a
|
|
|
Charging way
|
3 stage(constant current constant voltage Floating charge)
|
|
|
AC input voltage
|
80-150v/170-250v
|
|
|
By pass mode
|
|
|
|
By pass transfer time≤ 10ms
|
≤ 10ms
|
|
|
AVS protection function
|
|
|
|
AC input lower voltage
|
yes,shut down
|
|
|
AC input high voltage
|
yes,shut down
|
|
|
Time delay
|
17 seconds
|
|
|
protections
|
lower voltage alarm&shutdown over voltage overload
|
|
|
Dimension
|
39.5*26.5*11cm
|
|
|
Net weight
|
5kg
|
|
|
Gross weight
|
5.9kg
|
|
Available Socket Types:
