Quick Details
-
Size:
-
13000x2500x3950mm
-
Place of Origin:
-
Shandong, China
-
Manhole cover:
-
carbon steel/aluminum
-
Landing gear:
-
28t Heavy Duty Landing Gear
-
Axle:
-
YZ/FH brand
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
>30000 kg
-
Brand Name:
-
HCBZ
-
Size:
-
13000x2500x3950mm
-
Place of Origin:
-
Shandong, China
-
Manhole cover:
-
carbon steel/aluminum
-
Landing gear:
-
28t Heavy Duty Landing Gear
-
Axle:
-
YZ/FH brand
|
Tanker Body
|
|
|
|
Shape
|
Cylindrical
|
|
|
Dimension
|
9500-13000*2500*3900mm ( can be customized )
|
|
|
Volume
|
45m³ - 60 m³
|
|
|
Compartments
|
1 Compartments
|
|
|
Material
|
S30408 Q345
|
|
|
Design temperature
|
-196～50 ℃
|
|
|
Design pressure
|
0.64 MPa
|
|
|
Corrosion allowance
|
1 mm
|
|
|
Thermally insulation thickness/material
|
25mm / aluminum foil+Degreased fibre paper
|
|
|
Safety Valve
|
|
|
|
Type
|
DAH-25
|
|
|
Form
|
Full lift
|
|
|
Norminal pressure
|
4 MPa
|
|
|
Valve base size
|
20 mm
|
|
|
Rated pressure
|
0.69 MPa
|
|
|
Discharge-pressure
|
≤0.76 MPa
|
|
|
Return-pressure
|
≥0.63 MPa
|
|
|
Chassis
|
|
|
|
Main Beam
|
Q345B Carbon steel material
|
|
|
Axles
|
2 - 4 pcs 13 - 20tons BPW or Fuwa Axles
|
|
|
Suspenssion
|
Mechanical, Air, Bogie
|
|
|
Landing Leg
|
JOST E100
|
|
|
Brake system
|
6pcs T30/30 Brake Chambers, WABCO relay valve
|
|
|
Tire
|
12R22.5, 315/80R22.5, 12.00R24 Triangle Brand
|
|
|
King Pin
|
JOST 2" or 3.5 " Bolting Type
|
|
