Quick Details
-
Brand Name:
-
The Nile
-
Dimension(L*W*H):
-
11.2*2.75*4.2m
-
Weight:
-
1500 KG
-
Marketing Type:
-
New Product
-
Max feeding size:
-
150mm
-
Output size:
-
5-13mm
-
Capacity:
-
50-240t/h
-
Impact Crusher Motor Power:
-
160kw
-
Belt Conveyor width:
-
650mm
-
Belt conveyor speed:
-
0.8-2m/s
-
Vibratinf screen size:
-
4.8*1.8m
-
Size of bin:
-
4.9*1.7*1.4m
-
OEM:
-
yes
-
Factory visit:
-
Welcomed Warmly
Quick Details
-
Application:
-
Crushing And Screening
-
Capacity(t/h):
-
50-80t/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
The Nile
-
Dimension(L*W*H):
-
11.2*2.75*4.2m
-
Weight:
-
1500 KG
-
Marketing Type:
-
New Product
-
Max feeding size:
-
150mm
-
Output size:
-
5-13mm
-
Capacity:
-
50-240t/h
-
Impact Crusher Motor Power:
-
160kw
-
Belt Conveyor width:
-
650mm
-
Belt conveyor speed:
-
0.8-2m/s
-
Vibratinf screen size:
-
4.8*1.8m
-
Size of bin:
-
4.9*1.7*1.4m
-
OEM:
-
yes
-
Factory visit:
-
Welcomed Warmly
Products Description
Mobile crushing plant also named portable crusher station, is a new type of crushing equipment, researched and designed by our experienced engineers. The Nile Mobile jaw crusher station widely used in mines, coal mines, garbage and construction waste recycling, civil engineering, urban infrastructure, roads or construction sites etc.
Mobile Crushing Plant
Mobile jaw crusher station is mainly composed of feeder, jaw crusher and belt conveyor. The capacity is 85-650 tons per hour.
The machine adopts the integrated group operation mode, can work separately, eliminates the complex site infrastructure and auxiliary facilities installation of the split-component, and reduces the man-hour consumption.
Features of Mobile Crushing Plant
1.Move Easily.
It can go to the crushing place directly. It can move not only on the smooth road, but also on the bumpy road.
2.Compact Structure and Simple Operation.
Integrative equipment group with trailer save the working area. With generator, motor and control box on the trailer, it can work outdoor easily. Equipped with supporting facilities, it can be installed quickly and conveniently.
3.Easy to Operate
Operating system with imported direct servo technique can be easily and precisely controlled and travel in a high speed.
Technical Data
Mobile Crushing Plant - Type 1
Jaw Crusher Type
Mobile Crushing Plant - Type 2
Impact Crusher Type
Mobile Crushing Plant - Type 3
Cone Crusher Type
|
Item
|
NG938E69
|
NG1142E710
|
NG1349E912
|
|
Transport Length (mm)
|
12150
|
13000
|
14600
|
|
Transport Width (mm)
|
2550
|
2550
|
2550
|
|
Transport Height (mm)
|
3950
|
4400
|
4500
|
|
Max.Length (mm)
|
12150
|
13300
|
14600
|
|
Max.Width (mm)
|
2800
|
2950
|
3300
|
|
Max.Height (mm)
|
3960
|
4840
|
5300
|
|
Tire Configuration
|
Two Axis
|
Three Axis
|
Three Axis
|
|
Model of Crusher
|
PE600*900
|
PE750*1060
|
PE900*1200
|
|
Largest Feed Size (mm)
|
480
|
630
|
750
|
|
Capacity (t/h)
|
80-120
|
120-200
|
200-320
|
|
Feeder Type
|
GZD960*3800
|
GZD1100*4200
|
GZD1300*4900
|
|
Main Belt Type
|
B800*8.5m
|
B1000*9m
|
B1200*9.5m
|
|
Type of Generator Set (Optional) (kw)
|
200
|
250
|
300
|
|
Type of Iron Remover (Optional)
|
RCYD-8
|
RCYD-10
|
RCYD-12
|
