Main project
|
Technical Parameter
|
|
|
|
Main structural system
|
Model
|
HT-TC-3.5
|
|
|
|
Side length
|
3.5 meters
|
|
|
|
Edge width
|
3.5 meters
|
|
|
|
Top height
|
2.6M
|
|
|
|
Indoor area
|
9.62㎡
|
|
|
|
Number of circumferential lobes
|
8 petals
|
|
|
|
Frame material
|
6063-T5 aluminum profile (three colors optional)
|
|
|
|
Wall material
|
PC board 5.0mm thickness
|
|
|
|
Door system
|
Revolving sliding door
|
|
|
|
Wind load
|
100 km /h (0.5KN/m2)
|
|
|
□Indoor flooring (optional)
|
Height
|
100 m
|
|
|
|
Material
|
Aluminum profile round beam, aluminum profile keel, 18mmn solid wood laminate, surface PVC lock floor
|
|
|
Indoor intelligent lighting system
|
Top
|
LED main light source (remote control adjustable) standard
|
|
|
|
Bottom
|
LED auxiliary light source (remote control adjustable) standard
|
|
|
package weight
|
Packaging size (mm)
|
Wooden box size (mm) 2600x1500x1350
|
|
|
|
Volume
|
5.26 ㎡
|
|
|
|
Theoretical weight
|
418 kg/set (excluding floor base)
|
|
|
Optional accessories（"□" represents optional configuration.）
|
□ Indoor floor curtains □ Dimming sunroof □ Electric lift sunroof
□ Outdoor LED ambient light □ Fresh air ventilation fan
□ Air energy heating and cooling air conditioner □ Aluminum profile base □ Sunshade
|
|
|
|
Usage scenario
|
Various campsites/garden landscapes/hot spring vacations/water park lounges/leisure tourism vacations/internet famous homestays/specialty restaurants/villa sunrooms/gyms/chess and card tea rooms in the scenic area
|
|
|
|
Q
|
Are you a factory ?
|
|
A
|
Yes, our factory covers an area of 10000 square meters in Foshan and has over 80 employees, with our own R&D and design teams.
|
|
Q
|
What is your main product?
|
|
A
|
We can provide a comprehensive solution for sunrooms, including profiles, hardware, accessories, glass, and more.
|
|
Q
|
What are your strengths?
|
|
A
|
We are a one-stop procurement professional manufacturer of hardware for doors, windows, and curtain walls. Among them, our
Sunshine Room manufacturing is our greatest pride. We independently design and research, and our terrace and house sunrooms are one of the best in China. To provide customers with a comprehensive solution, our prices are not the cheapest, but our services help customers save more time and money |
|
Q
|
What is your delivery time?
|
|
A
|
Regular sunrooms take 25-35 days after confirming deposits and withdrawals, while door and window accessories take 5-15 days
after confirming deposits and withdrawals |
|
Q
|
What is your warranty ? What do we do in case of problems?
|
|
A
|
Provide a 10-year quality warranty, including a frame that does not fade or fall off, and hardware and accessories that function
properly under proper operation for 10-20 years. |
