Quick Details
-
Application:
-
Metering
-
Power:
-
Electric
-
Pressure:
-
High Pressure
-
Flow capacity:
-
0.15-3.6 CC/r OR 6-30(±3%) CC/r
-
Working speed:
-
5~200 r/min
-
Medium:
-
Fluid
-
Temperature:
-
200℃
-
Min inlet pressure:
-
less than 0.2Mpa
-
Max outlet pressure:
-
Less than 30 Mpa
-
Usage:
-
Glue;oil;water and others
Quick Details
-
Brand Name:
-
GN
-
Model Number:
-
CX-GWMP
-
Place of Origin:
-
Shanghai, China
-
Application:
-
Metering
-
Power:
-
Electric
-
Pressure:
-
High Pressure
-
Flow capacity:
-
0.15-3.6 CC/r OR 6-30(±3%) CC/r
-
Working speed:
-
5~200 r/min
-
Medium:
-
Fluid
-
Temperature:
-
200℃
-
Min inlet pressure:
-
less than 0.2Mpa
-
Max outlet pressure:
-
Less than 30 Mpa
-
Usage:
-
Glue;oil;water and others
|
|
|
|
Product Description
Parameters
| Model |
Displacement (CC/R) |
Total Height | Base Height | Min Inlet Pressure | Max Outpet Pressure | Accuracy | Temperature |
| GWMP-0.15 | 0.15 | 83 | 28.1 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
|
GWMP-0.3 |
0.3 | 85 | 30.2 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-0.6 | 0.6 | 85 | 32 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-1.2 | 1.2 | 90 | 34 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-2.4 | 2.4 | 100 | 42 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-3.6 | 3.6 | 105 | 50 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-6 | 6 | 130 | 41 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-9 | 9 | 135 | 46 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-12 | 12 | 140 | 51 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-15 | 15 | 145 | 56 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-20 | 20 | 150 | 64 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-30 | 30 | 165 | 80 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-40 | 40 | 90 | 215 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-50 | 50 | 97 | 215 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-60 | 60 | 104.5 | 230 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-75 | 75 | 112 | 230 | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-80 | 80 | Customized | Customized | <0.2Mpa | <30Mpa | +/-3% | 200℃ |
| GWMP-125 | 125 | Customized |
Customized |
<0.2Mpa | <30Mpa | +/-3% | 200℃ |
Note : Direction of rotation: clockwise from the axis of rotation
| Model | 6CC | 9CC | 12CC | 15CC | 20CC | 25CC | 30CC |
| A | 130 | 135 | 140 | 145 | 150 | 158 | 165 |
| B | 41 | 46 | 51 | 56 | 64 | 72 | 80 |
| Min Inlet Pressure | <0.2Mpa |
| Working Speed | 5~200 R/min |
| Medium | Fluid |
| Temperature | 200℃ |
| Max Outlet Pressure | <30Mpa |
| Flow Capacity | 6-30(+/-30)CC/R |
| Sealing | Combined seal |
| Model | 0.15CC | 0.3CC | 0.6CC | 1.2CC | 2.4CC | 3.2CC | 3.6CC |
| A | 83 | 85 | 85 | 90 | 100 | 103 | 105 |
| B | 28.1 | 30.2 | 32 | 34 | 42 | 47.6 | 50 |
| Min Inlet Pressure | <0.2Mpa |
| Working Speed | 5~200 R/min |
| Medium | Fluid |
| Temperature | 200℃ |
| Max Outlet Pressure | <30Mpa |
| Flow Capacity | 0.15-3.6(+/-3%)cc/r |
| Sealing | Combined seal |
