Quick Details
-
Model Number:
-
CVR W-3P&W-21P
-
Dimension:
-
600*650*750mm
-
Storage:
-
NA
-
SNR:
-
109dB
-
Output Power:
-
LF 600W(RMS)2400W(PEAK)
-
Format:
-
NA
-
Power Handling:
-
2000W
-
Output Section:
-
3-channel
-
Dispersion Pattern:
-
110°h* 7.5°V
-
Finish:
-
Water-Proof,Wear-Resistant Textured Black Paint
-
Enclosure:
-
Birch Plywood
-
Certification:
-
CE, RoHS
-
LF section nominal impedance:
-
8 ohm
-
HF section nominal impedance:
-
16 ohm
-
dimensions:
-
1100*405*595mm
Quick Details
-
Warranty:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR W-3P&W-21P
-
Model Number:
-
CVR W-3P&W-21P
-
Dimension:
-
600*650*750mm
-
Storage:
-
NA
-
SNR:
-
109dB
-
Output Power:
-
LF 600W(RMS)2400W(PEAK)
-
Format:
-
NA
-
Power Handling:
-
2000W
-
Output Section:
-
3-channel
-
Dispersion Pattern:
-
110°h* 7.5°V
-
Finish:
-
Water-Proof,Wear-Resistant Textured Black Paint
-
Enclosure:
-
Birch Plywood
-
Certification:
-
CE, RoHS
-
LF section nominal impedance:
-
8 ohm
-
HF section nominal impedance:
-
16 ohm
-
dimensions:
-
1100*405*595mm
| Model | W-3&W-3P(Active) |
| Type | Two-way Line array system |
| Frequency Response | 55Hz-18KHz±3dB |
| Power handling | LF 600W(RMS)2400W(PEAK) |
| HF 200W(RMS)800W(PEAK) | |
| Sensitivity | LF 105dB(1W@1M) |
| HF 109dB(1W@1M) | |
| Max SPL | LF 131dB(PEAK/1M) |
| HF 135dB(PEAK/1M) | |
| Drivers | LF 1×12"(310mm)neodymium woofer 75mm(3in)coil |
| HF 2×2.5" neodymium compression driver with65mm titanium diaphragm | |
| Nominal impedance | LF 8 ohm HF 8 ohm |
| Coverage | 110º H×10º V |
| Connectors | 2×NL4MP speakon |
| Finish | Textured high-density polyurethane coating |
| Enclosure Material | Birch Plywood |
| Dimensions | 600×347×451mm(W×H×D) |
| Packing Dimensions | 675×447×520mm(W×H×D)/0.16cbm |
| Net weight | 29kg(W-3)33kg(W-3P) |
| Gross weight | 32kg(W-3)36kg(W-3P) |
| Model | W-21&W-21P(Active) |
| Type | Sub-bass system |
| Frequency Response | 30Hz-400Hz±3dB |
| Power handling | 1500W(RMS)6000W(PEAK) |
| Sensitivity | 109dB(1W@1M) |
| Max SPL | 138dB(PEAK/1M) |
| Drivers | 1×21"(545mm)neodymium woofer 115mm(4.5in)coil |
| Nominal impedance | 8 ohm |
| Finish | Textured high-density polyurethane coating |
| Connectors | 2×NL4MP speakon |
| Enclosure Material | Plywood |
| Dimensions | 600×650×750mm(W×H×D) |
| Packing Dimensions | 825X675X760(W×H×D)0.42/cbm |
| Net weight | 70kg(W-21)73kg(W-21P) |
| Gross weight | 75kg(W-21)78kg(W-21P) |
*Quality Wood Enlosure - Birch Plywood and Plywood available.
*Detailed Cutting - Done by CNC accurated cutting machine .
*Environmental painting – Environmental protected and wearable.
*CE&RoHS certificate -for all products
*Strictly test before delivery - All products are under examination of our engineer teams
before dilivery.
*Delivery damage free - Quality carton boxs with firm belt and flight cases are applied.
C for creativity;V for versatility;R for realiability
Founded in 2005,Based in Guangzhou(China),CVR PRO-AUDIO co.,is a cutting edge professional sound reinforcement system manufactory.
We provides professional sound equipment for nightclubs, concerts,private parties,touring applications, corporate functions,
stadiums, churches, performing arts venues, theatres,conference rooms,meeting halls, live bands and any space where audio system are needed.
Our staff have a wide range of experience in pro sound engineering, offering unparalleled quality at great prices.
