Quick Details
-
Material:
-
EPS
-
Keyword:
-
Cotainer House
-
Size:
-
20ft 0r 40ft
-
Wall:
-
Rock Wool
-
Usage:
-
Family House
-
Window:
-
PVC Sliding Window
-
Structure:
-
Steel Luxury Container House
-
Transport and load:
-
40HQ Container
Quick Details
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
TSD
-
Project Solution Capability:
-
Others
-
Material:
-
EPS
-
Keyword:
-
Cotainer House
-
Size:
-
20ft 0r 40ft
-
Wall:
-
Rock Wool
-
Usage:
-
Family House
-
Window:
-
PVC Sliding Window
-
Structure:
-
Steel Luxury Container House
-
Transport and load:
-
40HQ Container
Products Description
OEM&ODM
TELL ME YOUR REQUIREMENT ,OUR PROFESSINAL TECHNOLOGY TEAM WILL OFFER YOU YOUR DREAM HOME.
Product Paramenters
|
Basic
information
|
Extended size (mm) L * W *H
|
L5900*W6300*H2480
|
|
|
Interior space (mm) L * W *H
|
L5640*W6140*H2240
|
|
|
Folding size (mm) L * W *H
|
L5900*W2200*H2480
|
|
|
Weight (KG)
|
2500
|
|
Frame
structure |
Main beam
|
Galvanized Square Tube 80 * 100 * 2.5MM Q235
|
|
|
Column
|
Galvanized fold 150 * 210 * 2.0MM Q235
|
|
|
Sub-frame
|
Galvanized Square Tube 40 * 60 * 1.5MM Q235
|
|
|
Box lifting head
|
Galvanized 210*150*160*4MM Q235
|
|
|
Hinge
|
Galvanized Thickened Hinge Q235
|
|
Floor
|
Intermediate floor
|
18mm cement floor
|
|
|
Floor on both sides
|
18mm Bamboo Rubber Board
|
|
Insulation
wall
|
Sidewall
|
75mm sandwich sandwich board, color roll double-sided 0.35 (sandwich material is rockwool, EPS, optional)
Standard sandwich material is 12kg / m3EPS |
|
|
Partition
|
50mm sandwich sandwich panel, colored steel plate substrate double-sided 0.35.
(sandwich material is rockwool, EPS, optional)
Standard sandwich material is 12kg / m3EPS |
|
|
Main Top and Side Top
|
50mm sandwich sandwich panel, colored steel plate substrate double-sided 0.35.
(sandwich material is rockwool, EPS, optional)
Standard sandwich material is 12kg / m3EPS |
|
Electrical
system
|
Parameter
|
National standard wire; Inlet 6, air conditioner socket 4, ordinary socket 2.5, lighting 1.5.
(Can be customized to meet the certification requirements of the circuit according to the country) 2, circuit breaker system; 2P63A total open 1, 2P43A/2P32A/1P20 shunt leakage protector each. 3, lighting; Three anti-LED ceiling lamps * 6. 4, socket; Standard international three-hole socket (socket standard can be configured according to customer requirements) |
|
Door and
window
system
|
Entrance door
|
Standard steel anti-theft door (can be customized broken bridge aluminum, titanium
magnesium alloy, aluminum alloy door) |
|
|
Window
|
Standard plastic steel double glass casement window (can be customized high-end
broken bridge aluminum window, aluminum alloy window) 930 * 930 * 6; 500 * 500 * 1 |
Process
Material
Framework
Wall panel
Windows
Usage Scenarios
Features
1. Space-saving: the double-wing expansion house can be flexibly extended and contracted, which effectively increases the area of use and at the same time reduces the occupation of ground space.
2. Environmental protection: Because it can be quickly set up and dismantled, the biplane expansion house can reduce construction waste and energy consumption, more environmentally friendly and recyclable, which is conducive to the protection of the environment and conservation of resources.
3. Flexible and versatile: the biplane expansion house can be customized to meet different aesthetic and functional needs.
4 Safety: Portable houses are usually built with prefabricated modules, with safe and reliable structure.
5 Good living experience: Biplane Expansion Houses have good heat preservation, insulation and soundproofing properties, and are also equipped with integrated circuits, lighting, furniture and other facilities to provide users with a comfortable living experience.
6. Multi-scenario application: the double-wing expansion house is suitable for house expansion, temporary residence, tourism and vacation, such as hotels, office space, residential multiple scenarios, providing users with a wide range of application options.
Exhibition
Detail
Power input &
Inlet and outlet water system
Graphene：
Fire protection and heat insulation
Bathroom：
Self-contained infrastructure
Packaging
