Quick Details
-
Filling Accuracy:
-
Semi-automatic
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
1000*1600*2000 mm
-
Weight:
-
450 KG
-
Product name:
-
Keg washer
-
Capacity:
-
10L , 20L,30L,50L
-
Advantage:
-
High Effiency
-
Material:
-
SUS304
-
Function:
-
Washing beer keg
-
After-sales Service Provided:
-
Video Technical Support
-
Heating way:
-
Steam or electric
-
Marketing Type:
-
New Product 2020
Quick Details
-
Machinery Capacity:
-
Other
-
Packaging Material:
-
Wood
-
Filling Material:
-
Beer
-
Filling Accuracy:
-
Semi-automatic
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
1000*1600*2000 mm
-
Weight:
-
450 KG
-
Product name:
-
Keg washer
-
Capacity:
-
10L , 20L,30L,50L
-
Advantage:
-
High Effiency
-
Material:
-
SUS304
-
Function:
-
Washing beer keg
-
After-sales Service Provided:
-
Video Technical Support
-
Heating way:
-
Steam or electric
-
Marketing Type:
-
New Product 2020
KEG WASHER EQUIPMENT DESCRIPTION LIST
Main technical parameters
|
Equipment Outer Dimensions |
2000* 1 6 00 *2000 mm |
|
Net Weight |
450KG |
|
Power |
Steam Heating: 3KW Electric Heating: 18KW |
|
Production Capacity |
100-120 kegs/H |
|
Washing Method |
Invert Washing |
|
Applicable Kegs |
Keg with Diameter 250-500mm, Height 360-600mm |
|
Heating Way |
Electric Heating or Steam Heating |
|
Power Supply Voltage |
AC 380V 50HZ (customized) |
Main function and feature
1 , All procedures are thoroughly controlled by SIEMENS programmable controller. All parameters (time values) can be adjusted without stopping the machine.
2, Two sets of washing process for customers to choose.
3 , Disinfectant and Caustic could be used repeatedly to save water
4 , Water tank possess heating function, the temperature can be displayed on screen.
5 , With steam sterilization function (user-selectable).
Working process:
cylinder pressing→ air blowing (draining residue) → water wash→ air blowing (drain) → caustic wash → air blowing (caustic recycle) → hot water wash
→ air blowing (drain) →water wash→ air blowing (drain) →sanitizer→ air blowing (recycle) →water wash→ air blowing (recycle)→steam sterilization
→ water wash→ air blowing (recycle)→CO 2 replace steam→CO 2 pressurize
