Photo AB glue , super liquid epoxy resin 3:1 adhesive

Photo AB glue , super liquid epoxy resin 3:1 adhesive

FOB Reference Price: Get Latest Price

≥1 Kilograms

US $4.8

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Shenzhen

Brand Name:: XZX

Model Number:: 2020 photo AB glue

Type:: Super liquid epoxy resin

Product name:: photo epoxy resin

Color:: Transparent

Appearance:: Liquid

Packing:: 5kg

Shelf life:: 12months

Mixing Ratio:: A:B=3:1

Material:: 100% Silicone

Viscosity:: low /middle/high viscosity

Samples:: Freely

OEM:: Acceptaple

Quick Details

CAS No.:: 7085-85-02

Other Names:: photo AB glue

EINECS No.:: 230-391-5

Place of Origin:: Shenzhen

Brand Name:: XZX

Model Number:: 2020 photo AB glue

Type:: Super liquid epoxy resin

Product name:: photo epoxy resin

Color:: Transparent

Appearance:: Liquid

Packing:: 5kg

Shelf life:: 12months

Mixing Ratio:: A:B=3:1

Material:: 100% Silicone

Viscosity:: low /middle/high viscosity

Samples:: Freely

OEM:: Acceptaple

Product Description

2020 photo AB Epoxy Resin glue is a two-component transparent epoxy resin adhesive,it's thin , it can be cured quickly and below characteristics: low mixing viscosity, good defoaming and high transparency; Excellent mechanical properties and low shrinkage after curing;

Pre-curing index：
Checking	EpoxyInspect Condition& Method	Epoxy resin(A)	Hardener(B)
Appearance	Eyeballing	Transparent Clear Liquid	Transparent Clear Liquid
Density	25°C g/cm³	1.1~1.2	0.9~1.1
Viscosity	25°C pa.s	800~1000	200~300
Storage Time	Room temperature and ventilation	12 months	12months

Post-curing index：
Item	Units & Conditions	XZX Epoxy Resin 2010A/B
Hardness	SHORE-D	>85
Volume Resistivity	25℃、Ω、CM	4.0×1015
Surface Resistivity	25℃、Ω	2.5×1014
Dielectric Strength	25℃、KV/MM	23
Linear Expansivity	CM/K	<6.0×10-5
Water Absorption	100℃/1H、%	<0.4
Vitrification Temperature	℃	>100
Operating Temperature	℃	-60--120

实物图（1张正面+1张侧面+1张背面+1张解析图含产品的长/高/宽/等信息）+装修效果案例（4张）总计8张

Detailed Images

Crystal Cealr Art Epoxy Resin

High Transparency

High Hardness

Yellow Resistant

No Bubbles

Self-leveling

High Quality

Usage

● proportion: A: B = 3:1 (weight ratio)
● usable time: 25℃×30-40 min (100g mixture)
● curing conditions: 80℃×1-1.5 hours (natural drying at 25℃ for 8-12 hours)
● the product surface needs to be kept dry and clean; Take the amount according to the ratio and weigh it accurately. Please remember that the ratio is the weight ratio rather than the volume ratio.
● IMPORTANT: * Control the stirring in one direction and pour into other container stirring,to make it stirred evenly, Then please timely pour the glue and try to use up the mixed glue within the available time
● if it is baked, basic curing will be completed after 3 hours. Take the product out of the oven and cool it naturally.

High Hardness

1. Hardness over 80 degrees, more harder than ordinary crystal hardness and more transparent.

2.After curing, the finished product is super high transparent, high hardness, no shrinkage, no warping, no cracking!

3.Super clear resin, eye visible to naked completely super clear transparent, no blur, yellow resistant, long time warranty !

Packing&Shipping

Epoxy Resin(A)	Hardener (B）	It could custom package
5KG/Barrel	5KG/Barrel	20KG/BOX
