Lighter quality
Better heat dissipation
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Genk
-
Dimension(L*W*H):
-
38*42*45cm
-
Weight:
-
35
-
Rated power/speed:
-
4.0/3600
-
Marketing Type:
-
New Tech
-
Code:
-
D178R
-
Starting system:
-
Recoil
-
Electric-starting:
-
Optional
-
Oil type air cleaner:
-
Optional
-
Size&Weight:
-
39*42*45 cm / 33 kg
-
Color/logo Customize:
-
Yes
-
Drop shipping:
-
Yes
-
Parts support:
-
Yes
-
Function:
-
Power Support
Quick Details
-
Displacement:
-
296CC
-
Emission Standard:
-
EURO 5
-
Power:
-
4.0 KW
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Genk
-
Dimension(L*W*H):
-
38*42*45cm
-
Weight:
-
35
-
Rated power/speed:
-
4.0/3600
-
Marketing Type:
-
New Tech
-
Code:
-
D178R
-
Starting system:
-
Recoil
-
Electric-starting:
-
Optional
-
Oil type air cleaner:
-
Optional
-
Size&Weight:
-
39*42*45 cm / 33 kg
-
Color/logo Customize:
-
Yes
-
Drop shipping:
-
Yes
-
Parts support:
-
Yes
-
Function:
-
Power Support
Product Overview
D178R Diesel Engine with 4.0 kw power and Low fuel consumption
FEATURES AT A GLANCE
Lighter quality
Better heat dissipation
Increase the silencer
Reduce noise
Metal material is stronger and more anti -collision
Stable voltage
Better for battery charging
More stable and safer
As Machinery factory
we give our buyer with different crankshaft size customization for best power solution
Taper Shaft
Thread shaft
Key Shaft
PRODUCT SPECIFICATIONS
|
Model
|
D173R
|
D178R
|
D178R-Slow
|
D186R
|
D186R-Slow
|
D192R
|
D11000E
|
||||||
|
Engine type
|
Single Cylinder ,Vertical ,Air-cooled, Four Stroke
|
Single
|
Single
|
Single
|
Single
|
Single
|
Single
|
||||||
|
Bore/Stroke-mm
|
73*59
|
78*62
|
78*62
|
86*72
|
86*72
|
92*75
|
100*80
|
||||||
|
Displacement-L
|
0.247
|
0.296
|
0.296
|
0.418
|
0.418
|
0.499
|
0.6951
|
||||||
|
Compression Ratio
|
20:1
|
20:1
|
20:1
|
19.5:1
|
19.5:1
|
19.5:1
|
19:1
|
||||||
|
Rated Speed-rpm
|
3000/
3600
|
3000/
3600
|
1500/
1800
|
3000/
3600
|
1500/
1800
|
3000/
3600
|
3000/
3600
|
||||||
|
Rated Power-KW
|
3.6
|
4.0
|
4.0
|
5.8
|
6.6
|
8.6
|
9.5
|
||||||
|
Rated Power-hp
|
4.0
|
4.2
|
4.5
|
6.5
|
7.0
|
9.2
|
10
|
||||||
|
Starting Type
|
Recoil/Electric(Optional 100% Copper core Electric Start)
|
Recoil/Electric
|
Recoil/Electric
|
Recoil/Electric
|
Recoil/Electric
|
|
Electric
|
||||||
|
Tank Volume-L
|
2.5
|
3.5
|
3.5
|
5.5
|
5.5
|
5.5
|
5.5
|
||||||
|
Oil Capacity-L
|
0.75
|
1.10
|
1.10
|
1.65
|
1.65
|
1.65
|
2.0
|
||||||
|
Fuel Brand
|
Diesel(summer),-10#winter)
|
Diesel(summer),-10#winter)
|
Diesel(summer),-10#winter)
|
Diesel(summer),-10#winter)
|
Diesel(summer),-10#winter)
|
|
|
||||||
|
The Oil Brand
|
SAE10W30(grode CD or above
|
SAE10W30(grode CD or above
|
SAE10W30(grode CD or above
|
SAE10W30(grode CD or above
|
SAE10W30(grode CD or above
|
|
|
||||||
|
Overall Dimensions-cm
|
34*38*42
|
38*42*45
|
38*42*45
|
42*44*50
|
42*45*50
|
42*44*50
|
42*49*55
|
||||||
|
Net Weight-kg
|
Recoil:27
Electric 31
|
Recoil:33
Electric:38
|
Recoil:33
Electric:38
|
Recoil:48
Electric:53
|
Recoil:48
Electric:53
|
Recoil:55
Electric:60
|
F:60
|
||||||
|
Turn To
|
Clockwise（from the flywheel)
|
Clockwise（from the flywheel
|
Clockwise（from the flywheel
|
Clockwise（from the flywheel
|
Clockwise（from the flywheel
|
|
|
||||||
Engine Parts Detailed Advantage
