Quick Details
-
Brand Name:
-
GnneCrius
-
OEM:
-
Acceptable OEM Service
-
Brand:
-
Accept OEM Brand
-
Color:
-
Customized Color
-
MPPT:
-
120A Solar Changer
-
ODM:
-
Accept ODM
-
Name:
-
Inverter Solar Power System
Quick Details
-
Type:
-
MPPT, PWM
-
Application:
-
Charger Controller, Collector Controller
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
GnneCrius
-
OEM:
-
Acceptable OEM Service
-
Brand:
-
Accept OEM Brand
-
Color:
-
Customized Color
-
MPPT:
-
120A Solar Changer
-
ODM:
-
Accept ODM
-
Name:
-
Inverter Solar Power System
Product Description
Certifications
|
INPUT
|
|
|
|
|
|
|
||||||
|
Maximum PV open circuit voltage
|
150V (at the lowest temperature)
|
|
|
|
|
|
||||||
|
|
138V (at standard temperature of 25℃)
|
|
|
|
|
|
||||||
|
Minimum PV voltage
|
20V/40V/60V/80V
|
|
|
|
|
|
||||||
|
Rated charge current
|
30A
|
40A
|
50A
|
60A
|
80A
|
100A
|
||||||
|
OUTPUT
|
|
|
|
|
|
|
||||||
|
System voltage
|
12V/24/36/48V auto
|
|
|
|
|
|
||||||
|
Rated discharge current
|
15A
|
20A
|
25A
|
30A
|
40A
|
50A
|
||||||
|
Own consumption
|
≤35mA
|
|
|
|
|
|
||||||
|
MPPT highest accuracy
|
99%
|
|
|
|
|
|
||||||
|
Maximum charging efficiency
|
97%
|
|
|
|
|
|
||||||
|
Charging control mode
|
Multi-stage (MPPT, Absorption, Float, Equalization, CV)
|
|
|
|
|
|
||||||
|
Float charge
|
13.8V/27.6V/41.4V/55.2V
|
|
|
|
|
|
||||||
|
Absorption charge
|
14.4V/28.8V/43.2V/57.6V
|
|
|
|
|
|
||||||
|
Equalization charge
|
14.6V/29.2V/43.8V/58.4V
|
|
|
|
|
|
||||||
|
Load disconnection (LVD)
|
10.8V/21.6V/32.4V/43.2V
|
|
|
|
|
|
||||||
|
Load reconnection (LVR)
|
12.6V/25.2V/37.8V/50.4V
|
|
|
|
|
|
||||||
|
Load control mode
|
Normal, light control, light and timing control, timing control, reverse light control
|
|
|
|
|
|
||||||
|
Light control point voltage
|
5V/10V/15V/20V
|
|
|
|
|
|
||||||
|
Battery type
|
GEL, SLD, FLD AND USR (default), LifePO4, Lithium batteries customization
|
|
|
|
|
|
||||||
|
OTHER
|
|
|
|
|
|
|
||||||
|
Human interface
|
LCD with backlight, 3 buttons
|
|
|
|
|
|
||||||
|
Cooling mode
|
AL alloy heat sink and cooling fan
|
|
|
|
|
|
||||||
|
Wiring
|
High current copper terminal ≤25mm2 (3AWG)
|
|
|
|
|
|
||||||
|
Temperature probe
|
Line length 3m
|
|
|
|
|
|
||||||
|
Communication mode
|
RS485, RJ45 port
|
|
|
|
|
|
||||||
|
Working temperature range
|
-20 ~ +55 ℃
|
|
|
|
|
|
||||||
|
Storage temperature range
|
-30 ~ +80 ℃
|
|
|
|
|
|
||||||
|
Humidity
|
10% - 90% no condendation
|
|
|
|
|
|
||||||
|
Product Size
|
250*190*95mm
|
|
280*210*100mm
|
|
350*230*112mm
|
|
||||||
|
Product Weight
|
2.3kg
|
|
3.5kg
|
|
4.6kg
|
|
||||||
|
Note: Please operate at the ambient temperature allowed by the controller. If the ambient temperature exceeds the allowable range
of the controller, please derate it. |
|
|
|
|
|
|
||||||
Exhibition
Logistics
FAQ
1: Are you factory or only company?
We have factory to produce new energy products, such ,solar modules, PPT controllers,control panels, as evcharger,etc.And also we have the agent for some other brand.
2:Why we can choose you?
1): Reliable-we are the real company, we dedicate in win-win2): Professional--we offer the solar panel productsexactly you want.
2):Factory-we have factory, so have compective price.
3):Custom-we have our own factory, so we can make customized ones, just give us your design.
3: How about the shipping cost?
If your goods is not large, we can send goods to you via express, such as FEDEX, DHL,EMS,TNT,etc.Ifyourgoods is large, we will send to you via sea or air, we can quote the price base on FOB,CIF &CNF asyou like,thenyou can choose whether use our forwarder or yours.
4:How about the price?Can you make it cheaper?
The price depends on the item your demand(quantity,design,size,length).
Final quotation accoring to receving full description of the item you want.
