Quick Details
-
Place of Origin:
-
GUA
-
Main Screen:
-
15.6 inch ips-LCD,LED backlight, 1920*1080, Multi-touch,G+G
-
Memory:
-
EMMC5.0 8GB DDR4 2GB
-
Speaker:
-
5W*1
-
Interfaces:
-
Power Port*1 RJ11Port*1 RJ12 Port*1 Typec USB*1 USB Host*4
-
Ethernet:
-
10M/100M
-
Communication:
-
4G/WIFI/Bluetooth
-
Code Scan:
-
Embedded 2D code module, supporting 1D / 2D
-
Second Screen:
-
15.6 inch ,1920*1080,VGA+LVDS synchronous / asynchronous dual display
-
NFC:
-
ISO/IEC 14443A,ISO/IEC 14443B,ISO/IEC 15693,MIFARE 1K/4K
-
Binocular Camera:
-
Color 650nm 720p / 30fps;black and white infrared 850nm 720p / 15fps
Quick Details
-
Model Number:
-
FH156A13-D
-
Country of Origin:
-
China
-
Brand Name:
-
Pay Device
-
Place of Origin:
-
GUA
-
Main Screen:
-
15.6 inch ips-LCD,LED backlight, 1920*1080, Multi-touch,G+G
-
Memory:
-
EMMC5.0 8GB DDR4 2GB
-
Speaker:
-
5W*1
-
Interfaces:
-
Power Port*1 RJ11Port*1 RJ12 Port*1 Typec USB*1 USB Host*4
-
Ethernet:
-
10M/100M
-
Communication:
-
4G/WIFI/Bluetooth
-
Code Scan:
-
Embedded 2D code module, supporting 1D / 2D
-
Second Screen:
-
15.6 inch ,1920*1080,VGA+LVDS synchronous / asynchronous dual display
-
NFC:
-
ISO/IEC 14443A,ISO/IEC 14443B,ISO/IEC 15693,MIFARE 1K/4K
-
Binocular Camera:
-
Color 650nm 720p / 30fps;black and white infrared 850nm 720p / 15fps
Products Description
|
Standard Configuration
|
|
|
|
|||
|
CPU
|
32Bit Quad-Core ARM Cortex-A17，up to 1.8GHz
|
Interfaces
|
power Port*1, RJ45*1,RS232 DB9*1 Micro USB OTG*1 USB Host 2.0*2, Micro SIM*1, 3.5mm Headphone jack*1
|
|||
|
Storage
|
EMMC5.0 8GB DDR3 2GB Card Slot Micro SD*1(Biggest Support 32G)
|
Ethernet
|
10M/100M
|
|||
|
Main Screen
|
15.6inch TFT LCD,,LED backlight, 1920*1080 Multi-touch,IPS Full Perspective，glass+glass
|
WIFI
|
IEEE 802.11b/g/n/d/e/h/i Enterprise level security which can apply WPA/WPA2 certification for WiFi.
|
|||
|
Speaker
|
Built-in speaker 5W*1 Audio Playback
|
OS
|
Android 7.1 Kernel 4.4
|
|||
|
Physical Buttons
|
Power button*1
|
Video
|
Video Hardware Decoding,Support HD1080p; support HTML web pages; Support video playback / video stream
|
|||
|
Bluetooth
|
Fully Qualified for Bluetooth 2.1 + EDR specification including both 2Mbps and 3Mbps modulation mode Fully qualified for Bluetooth,
3.0 Fully qualified for Bluetooth 4.0 Dual mode |
|
|
|||
|
Optional
|
|
|
|
|||
|
Second display
|
15.6 inch TFT LCD, 1920*1080 Android presentation api, support text, vedio, photo，Multi-touch,IPS Full Perspective，glass+glass
|
|
|
|||
|
Double camera
|
2M HDR 650nm 720P/30fps 2M B/W 850nm 720P/15fps
|
NFC
|
ISO/IEC 14443A,ISO/IEC 14443B,ISO/IEC 15693,MIFARE 1k/4K ,MIFARE DESFire,Sony FeliCa
|
|||
|
Other Parameters
|
|
|
|
|||
|
Machine Size
(main+customer)
|
393mm*307.4mm*30.5mm
393mm*242.4mm*30.5mm
|
N.W.
|
6.8KG
|
|||
|
CTN Size
|
490mm*390mm*170mm
|
CTN G.W.
|
8.05KG
|
|||
|
Work Environment
|
Operating temperature:0℃ ～ 40℃ Storage temperature : -20℃ ～ 70℃ Relative humidity: 30℅～90℅
|
Power Adapter
|
Input:100V～240VAC，50～60HZ Output:12VDC, 5A
|
|||
