Quick Details
-
Power (kW):
-
4.5
-
Applicable Industries:
-
woodworking
-
Total motor power:
-
4.5kw
-
Weight:
-
475kg
-
Surface thicknesser working table:
-
1300*350mm
-
Max.planing thickness:
-
3mm
-
Thicknesser working table:
-
300*450mm
-
Panel saw working table:
-
1600*320mm
-
Spindle moulder working table dimension:
-
800*30mm
-
Boring grooving working table dimension:
-
200*300mm
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
FUMA
-
Weight (KG):
-
500 KG
-
Power (kW):
-
4.5
-
Applicable Industries:
-
woodworking
-
Total motor power:
-
4.5kw
-
Weight:
-
475kg
-
Surface thicknesser working table:
-
1300*350mm
-
Max.planing thickness:
-
3mm
-
Thicknesser working table:
-
300*450mm
-
Panel saw working table:
-
1600*320mm
-
Spindle moulder working table dimension:
-
800*30mm
-
Boring grooving working table dimension:
-
200*300mm
MX5300A European Quality CE Combination Woodworking Machines 5 in 1
MX5300A is a combination ol mull purpose woodworking machine for solid wood andplaten Man functions : including sliding table saw, vertical miling, planer, thicknesser, tenon,driling and so on, one machino serves several purpose.
MX5300A with the advantages of small size ,multiple used, reasonable structure, flexible used and application scope wide.
MX5300A
Suitable small /medium enterprises, mould . homemade ,DIY workshops and decoration construction team
|
MX5300A |
Sawing |
MX5300A |
|
|
Worktable size |
300x1800mm |
Main saw out dia. |
300mm |
|
Cutter shaft dia. |
70mm |
Main saw inner dia. |
30mm |
|
Cutter shaft rotating speed |
5700 |
Max. Working height |
100mm |
|
Quantity of knifes |
3 pcs |
Max. Crosswise sawing width of rear worktable |
730mm |
|
Knifes size |
400x25x3mm |
Sawblade tilted angle range |
45° |
|
Max. Planning depth |
4mm |
Max. Main/tilted sawing depth |
75mm |
|
Thickness |
MX5300A |
Main saw rotating speed |
4500rpm |
|
Worktable size |
400x760mm |
Scoring saw out dia. |
80mm |
|
Feeding speed |
7m/1' |
Rear worktable siz |
330x1112mm |
|
Max. Working height |
220mm |
Scoring saw rotating speed |
7000rpm |
|
Min. Working height |
4mm |
Scoring saw inner dia. |
22mm |
|
Cutter shaft rotating speed |
5700rpm |
Working height |
4.0mm |
|
Motor power |
3 |
Motor power |
3 |
|
Mortiser |
MX5300A |
Shaper |
MX5300A |
|
Worktable size |
470*280mm |
Worktable size |
330x1112mm |
|
Crosswise stoke |
150mm |
Shaper spindle rotating speed |
7000/4400/3100/2000rpm |
|
Portait stoke |
120mm |
Shaper spindle dia. |
30mm |
|
Vertical stoke |
100mm |
Shaper spindle length |
105mm |
|
Driller shaft dia. |
16mm |
Shaper spindle vertical stoke |
115mm |
|
Rotating speed |
5700rpm |
Max. Shaper blade dia. |
180mm |
|
Max. Mortisering depth |
65mm |
Motor power |
3 |
|
Aluminum sliding table size |
MX5300A |
Surface planer |
MX5300A |
|
Sliding table size |
2270x265mm |
Motor power |
3 |
|
Table stoke |
2270/2200mm |
|
MX5300ACombination Machine
1, Main using: planer, saw, router, drilling, tenon ect for wood.
2, Feature: the cubage and area of the machine is small, reasonable construction ,multi-functions, agility and extensive using, is first choosing for vastness furniture manufacture factory.
3, The router section: it is a multi-function section, be used to saw and cut, tenon, panel edge, mill groove, planing , mend the machining edge of decorated wood line
