Zhengzhou LIVI A type galvanized chicken cages for laying hen poultry cage Chicken Layer Cage Used In Poultry Farm

Zhengzhou LIVI A type galvanized chicken cages for laying hen poultry cage Chicken Layer Cage Used In Poultry Farm

FOB Reference Price: Get Latest Price

≥10 Pieces

US $65

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: LIVI

Model Number:: A Type

Weight:: 60 KG

Surface Treatment:: Electrostatic Spray / Cold Galvanized / Hot Galvanized

Size:: 1950*350*380mm, etc

Capacity:: 96pcs / 128pcs / 160pcs / 240pcs / 288 pcs

Color:: Sliver

Feature:: Easy Installation

Usage:: Feeding chicken / Egg production

Lifespan:: 15-20 Years

Certification:: ISO9001:2008, CE

Product Name:: A type layer battery cages chickens

Quick Details

Type:: chicken cages

Material:: Low Carbon Steel Wire

Place of Origin:: Henan, China

Brand Name:: LIVI

Model Number:: A Type

Weight:: 60 KG

Surface Treatment:: Electrostatic Spray / Cold Galvanized / Hot Galvanized

Size:: 1950*350*380mm, etc

Capacity:: 96pcs / 128pcs / 160pcs / 240pcs / 288 pcs

Color:: Sliver

Feature:: Easy Installation

Usage:: Feeding chicken / Egg production

Lifespan:: 15-20 Years

Certification:: ISO9001:2008, CE

Product Name:: A type layer battery cages chickens

Chicken Cage System

		A Type Layer Cage With Automatic feeding, automatic water, automatic egg collecting and manure removing characteristics 15-20 Years Service Life Simple structure, low cost, good ventilation. The newly designed feed trough can help to save feed costs. Automatic equipment can save labor costandincrease.

H Type Layer Cage Realizing full automatic feeding, watering, dosing, egg collecting and manure removing,environmental controlling. 15-20 Years Service Life H-type equipment has a high density rate, which could save the land and reduce the investment rate. Fully enclosed breeding type can realize the separation of human and chicken, prevent cross-infection of diseases, reduce the cost of medication

		Broiler Chicken Cage System Broiler equipment could feed the broiler from 1 day to about 42 days. Number of chickens each unit area far exceeds the pan feeding system, saving large space. Completely isolation between manure and chicken decreases the chanceofdisease through infected feces, and lower mortality rate. The two layers are separated which is good for ventilation and improves thebreeding quantity.

Pullet Chicken Cage System According to the growth characteristics of chicken seedlings of different childbearing age, the special design of cage ensure the growth of chicken. Reasonable feed position and Number of chickens each unit area. lts adjustable drinking system can meet the daily drinking demand of one-day baby chick. Automatic belt manure remove system, dry and sanitary.

		Broiler Pan Feeding System Successful broiler growing system helps you easy start your modern farm. Economical and practical construction Free Matching Automatic Supporting System Low Maintenance Cost More economical and practical construction

Ps :If you have chicken house, we can give you a free customized design to feed more chicken with lowest price. If you have not chicken house, we can give you a free design about the chicken house size and help you to build the chicken house.

Automatic Feeding System

1.Mechanical transmission device running smoothly, low noise,long service life.
2.The feeding process all the use of automated control, it can adjust the amount of materials. It prevents the waste of feed.
3.Feed car with arched structure,high carrying capacity,compression deformation small.
4.Saving manpower,Saving feed,greatly improving the efficiency of large-scale farming.

Egg Collection system

Egg collecting machine including imported equipment, pick up egg plant, export device, buffer device, transmission device,sprocket, and the lifting chain, described by a number of egg pick up eggs device connected in parallel by the claw group down the chain above, The equipment and systems with anti-slip and without damage the egg function, can reduce the human and material expenses,and for large chicken farm.

1.The Egg belt is made of polypropylene yarn, corrosion-resistant and antibacterial .
2.Perfect roll out angle( 7° ) of the bottom mesh minimize the breakage( ≤0.5‰ ).
3.Powerful ability to collect eggs, collecting up to 20000 eggs per hour ,
4.collecting and conveying eggs between different chicken sheds.
5.Suitable for all types of chicken cages.

Manure Removing System

Clean chicken manure timely can reduce ammonia gas that can cause chicken’s respiratory diseases, reducing mortality.

The horizontal belt takes the chicken droppings out of the chicken house and the slanting belt can take the chicken droppings to the truck directly, so the whole farm has no bad smell and flies.

1.Scraper Type

The scraper type is suitable for A type cages, which can clean two or three rows. It can not only save some labor cost, but also save some investment in the whole project.

The cleaning speed is 6-10 meters per minute.

2. Conveyor Belt Type
1).Suitable for both A type cages and H type cages, which can reduce the labor intensity and labor cost, keep the chicken shed dry and clean.Each row needs a set of manure removing machine.

2).Manure removing belt we use is 1.1 mm PP material (polypropylene), corrosion-resistant and antibacterial.

3).Manure Clean system is designed with pressure rollers and rubber rollers, which reduces the problem of motor idling and deviation. It can be used for a long time without adjusting the belt.

The walking speed is 2-4 meters per minute.

Environment Control System

1.The whole system include exhaust fan, cooling pad, deflector, air-inlet windows.
2.Exhaust fan and cooling pad can maintain optimum temperature range

3.Exhaust fan and air-inlet windows make sure fresh air come in, and bring out the harmful gas like ammonia gas, ammonia gas which will cause respiratory disease.
4.Deflectors change cool air direction, to prevent chickens from catching cold.


Cooling Pad	Exhaust Fan	Air-inlet windows	Air Deflector

The optimal temperature range for a chicken coop is 13″C -26″C. best is 22″C. Proper temperature can improve the feed conversion ratio, increase egg production.

Above 26 degrees, it will increase the difficulty for chickens to dissipate heat, which will lead to stress response and increase mortality. Above 43″C, all the chickens will die.

CUSTOMER CASES

		Project Site: Pakistan Type: H Type Layer Chicken Cage Raising Quantity Per House: 50000 Chickens ________________________________ "Great service" We completed the construction work with the help of account managers and Chinese engineers.The automated chicken cages is durable . 5.0 Very Satisfied

Project Site: Benin, Nigeria Type: A Type Layer Chicken Cage Raising Quantity Per House: 20000 Chickens ________________________________ "Reliable Company" Got a lot of help from them.LIVI helps me start my chicken farm. I have learned a lot of technologies from them. My farm had a good benfit in the first time. 5.0 Very Satisfied

		Project Site: Ghana Type: H Type Broiler Chicken Cage Raising Quantity Per House: 51000 Chickens ________________________________ "Professional Farm Design" My farm still works fine and gets great raising results now. The frame is very solid.I can finish the transportation of broilers in one day. 5.0 Very Satisfied

Project Site: Zimbabwe Type: Broiler Floor Raising System Raising Quantity Per House: 30000 Chickens ________________________________ "Very Reliable " Livi is a reliable Chinese company. They has durable automated chicken cages and reliable service. I have also got a lot of help from them. Our cooperation is going very well. 5.0 Very Satisfied

Ps: If you have chicken house, we can give you a free customized design to feed more chicken with lowest price. If you have not chicken house, we can give you a free design about the chicken house size and help you to build the chicken house.

Package & delivery

FCL: cage mesh and cage frame are nude packing, accessories are in plastic bags and carton box.
LCL: types of bird layer egg chicken cage packed in wooden box and pallet.
For example: 48000 layers package need 2x40’GP+1x20GP
(300 sets layer cages. 1950mm*450mm*410mm. 160 birds/set)

FAQ

1.Q: Chicken cages can be customized?

A: Yes, We have a-type chicken cage and H type chicken cage now, and our all kinds of chicken cages can be customized design according to each client's demands, provide non-standard design of program and process flow chart to you.

2.Q: What kinds of chicken layer cage you can offer?

A:We can produce cage system, automatic feeding system, automatic egg collecting system, automatic manure removing system and automatic environmental control system.

3. Q: what's your payment and currency?

A: We accept different kinds of payment terms:

1) Accept payment of TT.

2) Accept L/C

3) Accept Alibaba credit guarantee payment

4) Westen Union, Paypal. e-Checking, Visa card, Master card, etc.

B:The currency we accept have USD, RMB, EUR, GBP, AUD.

4. Q: What's the MOQ? How many sets chicken cage for 20 feet container and 40HQ container?

A: Our MOQ is 40 sets, one 20 feet container can loading 80-100 sets, one 40HQ container can loading 160-200 sets chicken layer cages.

5. Q: What information do I need provide?

A: Normally, we need our customer provide below information:

1. Which kinds of chicken do you plant to feed? (layer, broiler or pullet)
