Quick Details
-
Voltage:
-
220v/380v/415v
-
Dimension(L*W*H):
-
3000*3150*900mm
-
Application:
-
furniture factory
-
Weight (KG):
-
750 KG
-
Max.Cutting Height at 90°(mm):
-
90mm
-
Max.Cutting Height at 45°(mm):
-
80mm
-
Max. Length of Workpiece (mm):
-
3000mm
-
After-sales Service Provided:
-
Field installation, commissioning and training
-
Power:
-
5.5kw+1.1kw
-
Weight:
-
750 kgs
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Hysen
-
Usage:
-
wood cutting
-
Voltage:
-
220v/380v/415v
-
Dimension(L*W*H):
-
3000*3150*900mm
-
Application:
-
furniture factory
-
Weight (KG):
-
750 KG
-
Max.Cutting Height at 90°(mm):
-
90mm
-
Max.Cutting Height at 45°(mm):
-
80mm
-
Max. Length of Workpiece (mm):
-
3000mm
-
After-sales Service Provided:
-
Field installation, commissioning and training
-
Power:
-
5.5kw+1.1kw
-
Weight:
-
750 kgs
Product Description
Deail Specification
|
Dimension of sliding table
|
3000×375mm
|
|
Gross cut capacity
|
3000mm
|
|
Width of cut between saw blade and rip fence
|
1250mm
|
|
Tilting saw group
|
0-45°
|
|
Diameter of main saw blade
|
300mm
|
|
Diameter of scoring saw blade
|
120 mm
|
|
Max cutting height(90°)
|
80mm
|
|
Speed of main saw spindle
|
4000/6000 r.p.m
|
|
Saw motor power
|
5.5 KW
|
|
Scoring saw motor power
|
1.1 KW
|
|
Main spindle diameter
|
30mm
|
|
Scoring saw spindle diameter
|
20mm
|
|
Speed of scoring saw spindle
|
8000 r.p.m
|
|
Weight
|
750 KGS
|
