Quick Details
-
Brand Name:
-
MD
-
Model Number:
-
MP12007
-
Battery Size:
-
90*70*101
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
0.6Kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
1C
-
Product name:
-
12v 7ah battery
-
Voltage:
-
12V 12.8V
-
Capacity:
-
7Ah
-
Cycle life:
-
>2000 cycles@1C 100% DOD
-
Size:
-
90*70*101mm
-
Internal Resistance:
-
≤10mΩ
-
Months Self Discharge:
-
<3%
-
LCD Display:
-
Customized
-
Cell type:
-
LiFePO4
-
Type:
-
4S1P
Quick Details
-
Storage Type:
-
dry, cool and ventilation
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
MD
-
Model Number:
-
MP12007
-
Battery Size:
-
90*70*101
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
0.6Kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
1C
-
Product name:
-
12v 7ah battery
-
Voltage:
-
12V 12.8V
-
Capacity:
-
7Ah
-
Cycle life:
-
>2000 cycles@1C 100% DOD
-
Size:
-
90*70*101mm
-
Internal Resistance:
-
≤10mΩ
-
Months Self Discharge:
-
<3%
-
LCD Display:
-
Customized
-
Cell type:
-
LiFePO4
-
Type:
-
4S1P
Product Description
| Electrical Characteristics | Model | MDP-12007 | ||||
| Nominal Voltage | 12.8V | |||||
| Nominal Capacity | 7Ah | |||||
| Internal Resistance | ≤10mΩ | |||||
| Cycle Life | >2000 cycles@1C 100% DOD | |||||
| Months Self Discharge | <3% | |||||
| Efficiency of Charge | 100%@0.5C | |||||
| Efficiency of Discharge | 96-99% @1C | |||||
| Standard Charge | Charge Cut-off Voltage | 14.6±0.2V | ||||
| Charge Mode | 0.2C to 14.6V, then 14.6V charge current to 0.02C(CC/CV) | |||||
| Standard Discharge | Max. Continuous Discharge Current | 7.2A | ||||
| Discharge Cut-off Voltage | 10V | |||||
| Environmental | Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity | ||||
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity | |||||
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity | |||||
| Water Dust Resistance | IP65 | |||||
| Mechanical | Cell&Method | 4S | ||||
| Package | ABS plastic case | |||||
| Terminal | M8 | |||||
| Dimension | 90*70*101 | |||||
| Weight | 0.6kg | |||||
| Display screen | Optional | |||||
| Bluetooth | Optional | |||||
