- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Ruijie
-
Product Name:
-
UHF RFID Reader Antenna
-
Gain:
-
10dBi
-
Polarization:
-
Circular
-
Beam width:
-
Hor:75° Ver:40°
-
VSWR:
-
≤1.4
-
Maximum power:
-
50W
-
Dimension:
-
420*240*30mm
-
Connector:
-
N-Female Or Customized
-
Radome material:
-
ABS
-
Color:
-
White
Quick Details
-
Frequency:
-
860-960mhz
-
Protocol:
-
ISO 18000-6C
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Ruijie
-
Product Name:
-
UHF RFID Reader Antenna
-
Gain:
-
10dBi
-
Polarization:
-
Circular
-
Beam width:
-
Hor:75° Ver:40°
-
VSWR:
-
≤1.4
-
Maximum power:
-
50W
-
Dimension:
-
420*240*30mm
-
Connector:
-
N-Female Or Customized
-
Radome material:
-
ABS
-
Color:
-
White
Product Description
Specification
|
Electrical Specifications
|
|
|
|
Frequency
|
902-928MHz
|
|
|
Gain
|
10dBi
|
|
|
Beam width
|
Hor：75° Ver：40°
|
|
|
Polarization
|
Circular
|
|
|
VSWR
|
≤1.4
|
|
|
F/B Ratio
|
≥20
|
|
|
Impedance
|
50Ω
|
|
|
Maximum power
|
50W
|
|
|
Lightning protection
|
DC Ground
|
|
|
Connector
|
N-Female
|
|
|
Mechanical Specifications
|
|
|
|
Dimension
|
420*240*30mm
|
|
|
Net weight
|
1.15kg
|
|
|
Packing size
|
45*25*5.5cm
|
|
|
Gross weight
|
1.95kg
|
|
|
Radome material
|
ABS
|
|
|
Radome colour
|
White
|
|
|
Operating temperature
|
-40-70℃
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
