Quick Details
-
Brand Name:
-
TONTEK
-
Model Number:
-
TPD94D5
-
Speed:
-
1500rpm
-
Weight:
-
1200KG
-
Alternator brand:
-
STAMFORD/MECC ALTE/Tontek
-
Open type weight:
-
1200KG
-
Open type:
-
1900x750x1350 MM
-
Generator standby power:
-
83KW /103KVA
-
Fuel consumption:
-
20.96L/h
-
Engine model:
-
WP4D100E200
-
Rated frequency:
-
50HZ
-
Phase and wire:
-
3 phase 4 wires
Quick Details
-
Rated Voltage:
-
400/230V (Can be adjusted)
-
Frequency:
-
50HZ
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
TONTEK
-
Model Number:
-
TPD94D5
-
Speed:
-
1500rpm
-
Weight:
-
1200KG
-
Alternator brand:
-
STAMFORD/MECC ALTE/Tontek
-
Open type weight:
-
1200KG
-
Open type:
-
1900x750x1350 MM
-
Generator standby power:
-
83KW /103KVA
-
Fuel consumption:
-
20.96L/h
-
Engine model:
-
WP4D100E200
-
Rated frequency:
-
50HZ
-
Phase and wire:
-
3 phase 4 wires
|
DIESEL GENERATOR DATA:
|
|
|
|
|
|||
|
Generator set model
|
: TPD94D5
|
|
|
|
|||
|
Generator rated power
|
: 75KW/94KVA
|
|
|
|
|||
|
Generator standby power
|
: 83KW /103KVA
|
|
|
|
|||
|
Rated frequency
|
: 50HZ
|
|
|
|
|||
|
Rated voltage
|
: 400/230V (Can be adjusted)
|
|
|
|
|||
|
Rated speed
|
: 1500RPM
|
|
|
|
|||
|
Fuel consumption
|
: 20.96L/h
|
|
|
|
|||
|
Open type size
|
: 1900x750x1350 MM
|
|
|
|
|||
|
Open type weight
|
: 1200 Kg
|
|
|
|
|||
|
ENGINE DATA
|
|
|
|
|
|||
|
Engine model:
|
: WP4D100E200
|
|
|
|
|||
|
Engine brand
|
: DEUTZ
|
|
|
|
|||
|
Engine rated power
|
: 90KW /112.5KVA
|
|
|
|
|||
|
Engine standby power
|
: 100KW/125 KVA
|
|
|
|
|||
|
Engine speed
|
: 1500RPM
|
|
|
|
|||
|
Bore & Stroke
|
: 105×130 mm
|
|
|
|
|||
|
Displacement
|
: 4 .5L
|
|
|
|
|||
|
Type
|
: In line,4 cylinders,4 stroke
|
|
|
|
|||
|
Aspiration
|
: Turbocharged/Turbocharged & Aftercooled
|
|
|
|
|||
|
Governor
|
: Mechanical/Electronic
|
|
|
|
|||
|
ALTERNATOR DATA:
|
|
|
|
|
|||
|
Alternator model
|
: UCI 274C
|
ECP34 2S4A
|
TP-75-4
|
|
|||
|
Alternator brand
|
: STAMFORD
|
MECC ALTE
|
TONTEK
|
|
|||
|
Rated power
|
: 80kW/100KVA
|
84kW/105KVA
|
75kW/93KVA
|
|
|||
|
Frequency
|
: 50HZ
|
|
|
|
|||
|
Speed
|
: 1500RPM
|
|
|
|
|||
|
Voltage
|
: 400/230V (Can be adjusted)
|
|
|
|
|||
|
Power factor
|
: 0.8 (lagging)
|
|
|
|
|||
|
Phase and wire
|
: 3 phase 4 wires
|
|
|
|
|||
|
Excite type
|
: Single Bearing, Close coupled. Brushless, self-exciting,AVR
|
|
|
|
|||
|
Protection class
|
: IP23
|
|
|
|
|||
|
Insulation class
|
: H
|
|
|
|
|||
Q: What is the power range of your generator sets?
A: We can provide 10 KVA to 4000KVA, with a voltage range of 110V~15000V and frequencies of 50Hz and 60Hz.
Q: What is the lead time?
A: 7 working days against the 30%T/T deposit
Q:What is your MOQ?
A: Our MOQ is 1 unit
Q:What about your warranty?
A:13 months or 1000 working hours,whichever comes first.
Q: What are your payment terms?
A: 30% TT as deposit,70% TT before Shipment or Irrevocable LC at sight.
Q: What is your company's production capacity?
A:150 Sets per month
Q: Can you supply OEM service
A: YES
