Quick Details
-
Detect Distance:
-
25mm adjustable(Standard distance for Metal)
-
Target Object:
-
Metal Objects or Non-Metal Objects
-
Output Current:
-
200mA
-
Material of Housing:
-
ABS Housing
-
IP Rating:
-
IP67 Water and Dust resistance
-
Operating temperature:
-
-15-+60C
-
Power supply:
-
AC 90-250V (or AC 24V)
-
Application:
-
Detect: Metal, Water level, Fluid, Powder, Pellet, Grain, food...etc.
Quick Details
-
Use:
-
Position Sensor
-
Place of Origin:
-
Guangdong, China
-
Approval:
-
CE/Reliable with 12 months guarantee
-
Detect Distance:
-
25mm adjustable(Standard distance for Metal)
-
Target Object:
-
Metal Objects or Non-Metal Objects
-
Output Current:
-
200mA
-
Material of Housing:
-
ABS Housing
-
IP Rating:
-
IP67 Water and Dust resistance
-
Operating temperature:
-
-15-+60C
-
Power supply:
-
AC 90-250V (or AC 24V)
-
Application:
-
Detect: Metal, Water level, Fluid, Powder, Pellet, Grain, food...etc.
IBEST F54 Plastic Capacitive Proximity Sensor/Switch
AC 2 Wire NO or NC Output / With 2M Cable
1.Features :
-- Style: rectangular out D=54mm, height=35mm.
-- Shielded type; SN=25mm, sensitivity adjustable.
-- DC 3-wire(10-30V DC), DC 4-wire(10-30V DC), AC 2-wire (90-250 AC) type
-- Connection mode: PVC cable=2M
-- With LED operation indicate lamp, easily identifiable.
-- Brass chrome plated, proof of oil, water acid, alkaline.
-- Standard sensing object: metal or non-metal objects.
-- Protection rate: IP67, water resistant
-- Over-current protection.
-- CE approved.
-- Widely applied in measuring, Counting, Rpm measuring in mechanism,paper manufacture light industry, chemical etc
-- Detect: Metal, Water level, Fluid, Powder, Pellet, Grain, food...etc.
| 2. Ordering Code: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
| 3. Technical Specifications: | ||||||||||||||||||
|
