Quick Details
-
Dimensions(L*W*H):
-
880(L)*940(w)*740(H)mm/1880*970*740
-
Weight:
-
180 KG
-
Print Head:
-
I3200UV*4
-
Color:
-
CMYKLcLm+White
-
Output Accuracy:
-
1800dpi
-
Printing Speed:
-
4pass:12 ㎡/h
-
Maximum Print Area:
-
620mm
-
Ink Type/ink supply system:
-
UV ink
-
Capacity:
-
1.8L/color
-
Heating System:
-
LED UV water-cooling curing system
-
Thickness of Material:
-
1.5-6mm adjustable
-
Weight of Material:
-
≤ 20kg
-
Type:
-
Inkjet Printer
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Printing Shops
-
Plate Type:
-
Roll-to-Roll Printer
-
Usage:
-
Label Printer, Card Printer, Tube Printer
-
Automatic Grade:
-
Automatic
-
Marketing Type:
-
New Product 2020
-
Voltage:
-
220v
-
Core Components:
-
printer head 13200
Quick Details
-
Print Dimension:
-
620mm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XinFlying
-
Dimensions(L*W*H):
-
880(L)*940(w)*740(H)mm/1880*970*740
-
Weight:
-
180 KG
-
Print Head:
-
I3200UV*4
-
Color:
-
CMYKLcLm+White
-
Output Accuracy:
-
1800dpi
-
Printing Speed:
-
4pass:12 ㎡/h
-
Maximum Print Area:
-
620mm
-
Ink Type/ink supply system:
-
UV ink
-
Capacity:
-
1.8L/color
-
Heating System:
-
LED UV water-cooling curing system
-
Thickness of Material:
-
1.5-6mm adjustable
-
Weight of Material:
-
≤ 20kg
-
Type:
-
Inkjet Printer
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Printing Shops
-
Plate Type:
-
Roll-to-Roll Printer
-
Usage:
-
Label Printer, Card Printer, Tube Printer
-
Automatic Grade:
-
Automatic
-
Marketing Type:
-
New Product 2020
-
Voltage:
-
220v
-
Core Components:
-
printer head 13200
After-Sale Service:
1. If you use our ink, we will always provide you with free repair service
2. technologists can speak fluent english and provide instant online support service
3. free technical training will be provided in the f
actory
4. we will send you spare parts and inks in lower price
5. we can issue you excludsive dealership after we confirm our cooperation and we will 100% loyal to our dealers
6. we can arrange technicians to visit you for supporting the booth and training freely if you display our machines in exhibition.
Machine Maintenance Instructions:
1. As for the ink cap, scraper and lifting plate clean, must be kept clean all the time.
2. Need to put some lubricating oil on the trolley track for every half a month or for every month .
3. Grating need be wiped with dry clean fabric for every month.
4. Need to put some water into the ink stack cap while the the machine is printing. It greatly keeps the ink cap wet to prevent agglomeration and the print head blocked.
5. It is best to turn on the machine in two or three days if you do not use the machine for long time. And print the test strip or print some tasks to prevent the print head blocked.
6. The machine need to be kept cleaned all the time . If can kept like a new machine, which will better.
FAQ
Q: What ’ s the machine installation?
A: We provide the machine usage & installation videos and instruction manual, afford the 24 hour online service support for oversea customers. If need, we could provide the on-site installation and training service.
Q: How about the machine ’ s package and transportation ?
A: Each machine before leave the factory will be protected by film, be f asten ed on the bottom of the wooden case with iron nails , after the machine be packed, we will choose the transportation way and export service according customer ’ s requirement.
Q: How about the machine ’ s maintenance ?
A : With warranty of whole printer ( not included the printer head) , simultaneously we will provide the lifetime warranty if use together with our ink. Also our after-sales engineers will provide 24 hour online technical consulting service.
