Quick Details
-
Model Number:
-
HG-602PC-4
-
Battery lifetime:
-
No battery
-
Power supply:
-
9-35V
-
Senor:
-
Photoelectric Sensor
-
Output:
-
relay output,NO/NC
-
connect:
-
2wired,4wired for choose
-
Material:
-
ABS plastic,inner metal shield
-
Alarm decibel:
-
Louder than 85dB
-
Alarm method:
-
Sound&flash alarm
-
Life span:
-
10years or more
-
Market:
-
all over the world
-
Application:
-
Home,office,hospital,school,commercial area,public area,etc
Quick Details
-
Special Features:
-
Network,wired
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
HG-602PC-4
-
Battery lifetime:
-
No battery
-
Power supply:
-
9-35V
-
Senor:
-
Photoelectric Sensor
-
Output:
-
relay output,NO/NC
-
connect:
-
2wired,4wired for choose
-
Material:
-
ABS plastic,inner metal shield
-
Alarm decibel:
-
Louder than 85dB
-
Alarm method:
-
Sound&flash alarm
-
Life span:
-
10years or more
-
Market:
-
all over the world
-
Application:
-
Home,office,hospital,school,commercial area,public area,etc
Item: Fire Alarm Wired Conventional Photoelectric 4wired cigarette smoke detector
Specifications:
Power supply non-polar input:DC 9V~35V
Stainless steel shield,Anti-RFI;SMT adopted,high stability.
Dustproof,mothproof and anti-light interference design.
MCU processing adopted,eliminate false alarm.
Remote LED indicator.
Power-off reset.
Relay output ,NO/NC
detection sensitivity:2.06%/ft
Dimension: Φ103*53mm .
Photoelectric sensor
Red LED indicator
High sensitivity
Technical Parameter:
|
Product Type
|
2 wire
|
4 wire
|
|
|
Standby current
|
55uA
|
500uA(Relay N.O) 12mA(Relay N.C)
|
|
|
Alarm current
|
35mA@DC12V 60mA@DC24V
|
18mA(Relay N.O) 10mA(Relay N.C)
|
|
|
Alarm indication
|
Red LED ON
|
|
|
|
Temperature range
|
.-10°C-+50°C
|
|
|
|
Humidity
|
0%-95%RH(NO CONDENSATION)
|
|
|
|
Alarm output
|
remote LED
|
relay output
|
|
|
Contact rating
|
N/A
|
0.5A@DC28V
|
|
|
Sensitivity
|
0.5dB/m(±0.1dB/m)
|
|
|
|
Dimension
|
103mm diameter *53mm deep
|
|
|
