Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
FTS-5000
-
Input Voltage:
-
24VDC/48V DC(optional)
-
Output Voltage:
-
110VAC /220VAC (Optional)
-
Output Current:
-
50A
-
Output Frequency:
-
50Hz/60Hz(optional)
-
Size:
-
63*28*20CM
-
Certificate:
-
CE & FCC
-
Warranty:
-
1 years
-
Weight:
-
33.5(kg)
-
Color:
-
silvery
-
Product name:
-
DC Inverter
-
Output waveform:
-
Pure Sine Waveform
-
Application:
-
Solar Power System Home/off grid power sytem for industry
-
Inverter type:
-
Off-grid Inverter
-
Peak power:
-
15000W
-
Display:
-
LCD+LED Display
-
Communications:
-
MODBUS/ Profibus/ CANlink/ RS485
-
Protection:
-
Overcharge ,overload
-
Battery type:
-
Lead Acid Battery,lithium battery,Gel battery
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
92%
-
Place of Origin:
-
China
-
Model Number:
-
FTS-5000
-
Input Voltage:
-
24VDC/48V DC(optional)
-
Output Voltage:
-
110VAC /220VAC (Optional)
-
Output Current:
-
50A
-
Output Frequency:
-
50Hz/60Hz(optional)
-
Size:
-
63*28*20CM
-
Certificate:
-
CE & FCC
-
Warranty:
-
1 years
-
Weight:
-
33.5(kg)
-
Color:
-
silvery
-
Product name:
-
DC Inverter
-
Output waveform:
-
Pure Sine Waveform
-
Application:
-
Solar Power System Home/off grid power sytem for industry
-
Inverter type:
-
Off-grid Inverter
-
Peak power:
-
15000W
-
Display:
-
LCD+LED Display
-
Communications:
-
MODBUS/ Profibus/ CANlink/ RS485
-
Protection:
-
Overcharge ,overload
-
Battery type:
-
Lead Acid Battery,lithium battery,Gel battery
Product Description
INVERTER CONTROL INTEGRATION
Pure sine wave off-line optical storage, optional high-power charging current, optional input voltage range of household appliances and personal computers, configurable mains / solar input priority through LCD settings, compatible with AC power supply or generator power supply, and automatic restart when mains power is restored
SIMPLE DESIGN AND INSTALLATION
The power storage wall is simple to install and simple in design, which can be matched with various home styles. The compact integrated structure provides a variety of installation options for indoor or outdoor spaces.
Product Paramenters
|
Model
|
|
PN-3KW-24V
|
PN-3KW-48V
|
PN-5KW-48V
|
|||
|
MaxPVArrayPower
|
|
5000W
|
|
|
|||
|
RatedOutputPower
|
|
3000W
|
3200W
|
5500W
|
|||
|
MaxPVVoc
|
|
500VDC
|
|
|
|||
|
MPPTRangeOperatingVoltage
|
|
120-450VDC
|
|
|
|||
|
Output
|
NominalOutputVoltage
|
220/230/240VAC
|
|
|
|||
|
|
OutputVoltageRange
|
184-265VAC
|
|
|
|||
|
|
NominalOutputCurrent
|
13.6A/13.0A/12.5A
|
14.5A/13.9A/13.3A
|
25A/23.9A/22.9A
|
|||
|
|
OutputWaveform
|
Puresinewave
|
|
|
|||
|
Input
|
Efficiency
|
upto93.5%
|
|
|
|||
|
|
InputVoltageRange
|
120-280VAC
|
|
|
|||
|
|
Frequency
|
50Hz/60Hz(Autosensing)
|
|
|
|||
|
|
NominalOutputVoltage
|
220/230/240VAC
|
|
|
|||
|
NominalDCVoltage
|
|
24VDC
|
48VDC
|
|
|||
|
MaxSolarChargeCurrent
|
|
90A
|
|
|
|||
|
MaxACChargeCurrent
|
|
60A
|
|
|
|||
|
MaxOutputPower
|
|
3000W
|
3200W
|
5500W
|
|||
|
SurgePower
|
|
6000W
|
6400W
|
11000W
|
|||
|
AutomaticTransferTime
|
|
<8ms
|
|
|
|||
|
Communication
|
|
USB/RS232/⼲接点Dry-contact
|
|
|
|||
|
Dimension(L*W*H)cm
|
|
115x300x400
|
|
|
|||
|
N.W./Unit(kg)
|
|
9
|
|
10
|
|||
