Quick Details
-
Warranty(Year):
-
2-Year
-
Lamp Luminous Efficiency(lm/w):
-
380w
-
Input Voltage(V):
-
AC100-240V/50-60Hz
-
Lamp Luminous Flux(lm):
-
8000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
2000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ChengWen
-
Emitting Color:
-
Full coclor
-
Color wheel:
-
14 Colors +open
-
Gobo wheel:
-
17gobos + white light
-
Prism:
-
8 mirrors, 8+16+24 honeycomb mirrors
-
Pan/Tilt:
-
Pan: 540 (16bit) Tilt: 270 (16bit)
-
Frost:
-
With frost effect
-
Dimmer:
-
0-100% Linear Dimming
-
Strobe:
-
0-20 Times/sec
-
Control mode:
-
DMX512/Automatic/master-slave/sound
-
Installed method:
-
Upside down/horizontal
-
Feature:
-
High temperature protection
Quick Details
-
Color Temperature(CCT):
-
6000K (Daylight Alert)
-
Type:
-
Beam Lights
-
Application:
-
Stage event concert, etc...
-
Warranty(Year):
-
2-Year
-
Lamp Luminous Efficiency(lm/w):
-
380w
-
Input Voltage(V):
-
AC100-240V/50-60Hz
-
Lamp Luminous Flux(lm):
-
8000
-
CRI (Ra>):
-
90
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
2000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ChengWen
-
Emitting Color:
-
Full coclor
-
Color wheel:
-
14 Colors +open
-
Gobo wheel:
-
17gobos + white light
-
Prism:
-
8 mirrors, 8+16+24 honeycomb mirrors
-
Pan/Tilt:
-
Pan: 540 (16bit) Tilt: 270 (16bit)
-
Frost:
-
With frost effect
-
Dimmer:
-
0-100% Linear Dimming
-
Strobe:
-
0-20 Times/sec
-
Control mode:
-
DMX512/Automatic/master-slave/sound
-
Installed method:
-
Upside down/horizontal
-
Feature:
-
High temperature protection
Product Description
Specification
Voltage: AC90-2400V; 50-60Hz
Total power: 450W
Light source: 18R 380W
Input voltage/frequency: AC100V-240V, 50/60Hz
Beam angle: 3.8°
Control channels: 20/16 standard DMX channels
ELECTRONIC FOCUS: 20 meters, 150000 LUX
Operation mode: voice control, self-propelled, master-slave, DMX 512
Color wheel: 14 colors + white light, linear color conversion and rainbow effect
Pattern plate: 17 patterns + white circle
Prism: Two independent prism discs (8, 16, 24, 32, 48 prisms can be selected)
The prism and the prism are free to rotate forward and reverse, and have the function of prism positioning, and the prism can be superimposed to form a composite effect
Focusing: DMX linear high-definition focusing, the pattern distance and clarity can be adjusted freely.
Atomization: The built-in atomizing mirror can generate softening effect adjustment, 0%~100% linear atomization, with colorful effect
Strobe: Double-chip high-speed strobe, 1-15 times/second ultra-high-speed strobe effect.
Dimming: 0-100% mechanical linear dimming
Horizontal/Vertical: horizontal scanning angle 540°, vertical scanning angle 270°,
8 or 16Bit precision fine-tuning, automatic return correction function
Display interface: LCD liquid crystal display interface, can switch between Chinese and English display
Lamp housing: high temperature resistant flame retardant engineering plastics and alloy materials
Protection class: IP20
Dimensions: L380xW280xH600mm
Package size: L460xW410xH600mm
Net weight: 18.3KGS
