Quick Details
-
Model Number:
-
BO-100C
-
Power:
-
TU-26 gasoline engine
-
Spray capacity:
-
3-8L/min
-
working pressure:
-
1.5-2.5Mpa
-
Rotational speed:
-
800-1000r/min
-
Range:
-
10-12m
-
Weight:
-
40kg
-
Medicine box capacity:
-
100L
-
Overall Dimension:
-
1050*650*850mm
Quick Details
-
Sprayer Type:
-
Pump
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Blue Ocean
-
Model Number:
-
BO-100C
-
Power:
-
TU-26 gasoline engine
-
Spray capacity:
-
3-8L/min
-
working pressure:
-
1.5-2.5Mpa
-
Rotational speed:
-
800-1000r/min
-
Range:
-
10-12m
-
Weight:
-
40kg
-
Medicine box capacity:
-
100L
-
Overall Dimension:
-
1050*650*850mm
Product Description
Specification
|
Place of Origin
|
China
|
|
Brand Name
|
Blue Ocean
|
|
Model Number
|
BO-100C
|
|
Power
|
TU-26 gasoline engine
|
|
Spray capacity(L/min)
|
3-8L/min
|
|
working pressure
|
1.5-2.5Mpa
|
|
Rotational speed
|
800-1000r/min
|
|
Range
|
10-12m
|
|
Weight
|
40kg
|
|
Medicine box capacity
|
100L
|
|
Overall Dimension(L*W*H)
|
1050*650*850mm
|
Scope of application
The multi-functional dispenser has the advantages of ultra-fine droplets, simple mechanical transmission and good handling performance. It can be used with gasoline engine to greatly enhance the operability. The driver can easily operate independently, save water and medicine evenly, and can lengthen the length of the output tube at will. The multifunctional dispenser can be fully applied to the complex terrain of villages and towns and rural areas, and it can show the machine's performance in a large area of farmland Excellent and efficient, spraying area can reach 20 mu per hour, spraying efficiency and quality are greatly increased.
Operation method:
Open the carton, check the accessories and tools according to the packing list, read the instructions carefully, and be familiar with the machine structure and the name of each part.
Instruction for use:
Open the fuel tank cap and add clean 93 gasoline into the funnel with filter screen. The maximum fuel filling amount should not exceed the maximum mark of the oil tank. After filling, the cover should be tightened to prevent air leakage and oil leakage. Fill the liquid medicine, open the lid of the medicine barrel, and add the diluted liquid into the medicine barrel through the funnel with filter screen. The filling amount of the liquid medicine should not exceed the maximum scale line. After that, tighten the cover (both caps should be tightened), which is subject to no water leakage and air leakage.
Product features:
1. convenient start-up, compact structure, convenient transportation, long range, good atomization effect, large operation range, special return liquid agitator, good spraying effect, simple maintenance and long service life.
2. Perfect product function, vacuum tire in front wheel, brake in rear wheel, high efficiency, easy to push and pull;
3. High power, automatic mixing, good atomization, long range (high), easy operation and maintenance;
Scope of application:
1. Spraying pesticides in fields, orchards, flower beds, seedlings, vegetable greenhouses, tea gardens,
lawns and other fields to prevent and control diseases and insect pests, as well as pumping and sprinkling irrigation, etc;
2.Sterilization and epidemic prevention in public places, garbage sites and large areas after natural disasters;
3. Cleaning vehicles and sites.
