- Product Details
- {{item.text}}
Quick Details
-
Interface Type:
-
PS/2, usb
-
Keyboard Standard:
-
76 Keys
-
Brand Name:
-
HCCTG
-
Model Number:
-
KB76M
-
Place of Origin:
-
Guangdong, China
-
Item:
-
76 Keys Programming POS Keyboard
-
Key Number:
-
76 Keys
-
Electronics Lock:
-
6 section of electronic locks
-
Material:
-
TPU Keys+Plastic Shell
-
Software Compatibility:
-
Window ME/ 9X/2K/ XP/7/8/10
-
Memory:
-
All programmed data are stored in EEPROM
-
Cards:
-
Comply with ISO 7812
-
Accessories:
-
RJ45 Y Cable with PS/2 & USB, Keycap Puller,1x & 2 Transparent Caps
Quick Details
-
Operation Style:
-
Mechanical
-
Style:
-
Standard, Multimedia
-
Type:
-
Programming POS Keyboard
-
Interface Type:
-
PS/2, usb
-
Keyboard Standard:
-
76 Keys
-
Brand Name:
-
HCCTG
-
Model Number:
-
KB76M
-
Place of Origin:
-
Guangdong, China
-
Item:
-
76 Keys Programming POS Keyboard
-
Key Number:
-
76 Keys
-
Electronics Lock:
-
6 section of electronic locks
-
Material:
-
TPU Keys+Plastic Shell
-
Software Compatibility:
-
Window ME/ 9X/2K/ XP/7/8/10
-
Memory:
-
All programmed data are stored in EEPROM
-
Cards:
-
Comply with ISO 7812
-
Accessories:
-
RJ45 Y Cable with PS/2 & USB, Keycap Puller,1x & 2 Transparent Caps
Products Description
|
Key Number
|
76 keys
|
|
Key Switch Mechanism
|
Membrane‐type Key Switch with 12 million life cycle time
|
|
Total Travel Distance
|
4 + 0.5mm / 2 + 0.6mm
|
|
Key Force (Peak Load
|
60 + 20cN
|
|
Interface / Power
|
USB: +5VDC + 10% / < 100mA
|
|
|
PS/2: +5VDC + 10% / < 100mA
|
|
Cable
|
USB cable stored on the back
|
|
Programmable Features
|
|
|
|
|||
|
Programmable Keys
|
|
All keys can be programmable
|
|
|||
|
Mufti-Level Programming
|
|
support max 6 levels
|
|
|||
|
Time Delay Support
|
|
Provide a variable time delay, 0.5 sec per interval
|
|
|||
|
True Keyboard Function
|
|
Provide true keyboard wedge function, operated with or without the normal
|
|
|||
|
Software Compatibility
|
|
Support USB programming in Window ME/ 9X/2K/ XP/7/8/10
|
|
|||
|
Memory
|
|
All programmed data are stored in EEPROM, without battery
|
|
|||
|
Magnetic Stripe Card Reader Specification
|
|
|
|
|||
|
Card
|
|
Comply with ISO 7812, IBM standards, AAMVA, JIS - 2
|
|
|||
|
Programmable Support
|
|
Programmable MSR setting for Header, Tailor, Separator, Suffix and Prefix
|
|
|||
|
ISO Card Track
|
Track 1
|
210BPI with max 76 characters
|
|
|||
|
|
Track 2
|
210BPI with max 107 characters or 75BPI with max 37 characters
|
|
|||
|
|
Track 3
|
210BPI with max 107 characters
|
|
|||
|
LED's Indicator / Buzzer
|
|
Power, OK and ERROR / Buzzer
|
|
|||
|
Swipe Speed / Head Life‐Cycle
|
|
10 ~ 180 cm/sec. / 500, 000 swipes
|
|
|||
|
Others
|
|
|
|
|||
|
Electronics Lock
|
|
|
6 section of electronic locks for different level users
|
|||
|
Environment
|
Operating
|
|
0℃ ~ 50℃ (32°F ~ 122°F) , 10% ~ 90% (no condensation)
|
|||
|
Physical
|
Storage
|
|
- 20℃ ~ 55℃ (-4°F ~ 131°F) , 10% ~ 90% (no condensation)
|
|||
|
|
Dim. / Weight
|
|
345 (L) x 160 (D) x 40 (H) mm, including MSR/ 1102g (NW)
|
|||
|
|
Box / Weight
|
|
385 (L) x 196 (D) x 57 (H) mm / 1370 g (GW)
|
|||
|
Accessories
|
|
|
RJ45 Y Cable with PS/2 & USB interface, Key cap Puller, 1x and 2x Transparent Caps, Electronic keys
|
|||
