Selective wave soldering is a special form of wave soldering invented to meet the development requirements of through-hole components soldering. It is mainly suitable for the soldering of through-hole components in high-end electronic products. For example: military electronic products, automotive electronics, switching power supply products and other industries which require higher soldering reliability. I.C.T online selective wave soldering is a high performance equipment developed and assembled in China. for higher flexibility or multiwave soldering for high-volume processes.product changes without downtime even in multiwave processes, parallel process due to the
separation of fluxing, preheating and soldering, operation of up to two spray heads, up to five lower preheating with optional upper convectionheating, perfect for the connection to assembly stands and periphery, connection to traceability systems for process control.
- Product Details
- {{item.text}}
Quick Details
-
Rated Capacity:
-
5300w
-
Voltage:
-
220v
-
Current:
-
alternating current
-
Dimensions:
-
2900X1160X1500
-
Usage:
-
Welding machine, PCBA Production Line
-
Weight (KG):
-
790 KG
-
Product name:
-
Small Selective Soldering Machine Suneast
-
Applicable Components:
-
BGA/chip
-
Package:
-
Vaccum Package
-
Delivery:
-
Within 30 Days
-
Size:
-
4200*1250*1500mm
-
Power Supply:
-
3P5W,380/220V 50Hz
-
Weight:
-
1500KG
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
I.C.T
-
Rated Duty Cycle:
-
100%
-
Rated Capacity:
-
5300w
-
Voltage:
-
220v
-
Current:
-
alternating current
-
Dimensions:
-
2900X1160X1500
-
Usage:
-
Welding machine, PCBA Production Line
-
Weight (KG):
-
790 KG
-
Product name:
-
Small Selective Soldering Machine Suneast
-
Applicable Components:
-
BGA/chip
-
Package:
-
Vaccum Package
-
Delivery:
-
Within 30 Days
-
Size:
-
4200*1250*1500mm
-
Power Supply:
-
3P5W,380/220V 50Hz
-
Weight:
-
1500KG
C Small Selective Soldering Machine Suneast Conformal Coating Machine Conformal Coating Machine Selective China
I.C.T
On-line Selective Wave Soldering Machine
If You Need More Details About The I.C.T
Selective Wave Soldering Machine
, Please
Click Here.
|
Model
|
SS540
|
SS550
|
SS550D
|
SS550DD
|
|||
|
Flux Storage Tank
|
1L
|
1L
|
2L
|
2L
|
|||
|
Preheating Mode
|
IR Heating
|
Hot air and IR
|
Hot air and IR
|
Hot air and IR
|
|||
|
Preheating Zone
|
Top: 2, Bottom: 1
|
Top hot air: 2, Bottom IR: 1
|
|
|
|||
|
Max PCB Size
|
500*500mm
|
|
|
|
|||
|
PCB Replacement
|
Online
|
|
|
|
|||
|
N2
|
Purity of N2: 99.999%, 25 L/min, Outer diameter Φ6mm
|
|
|
|
|||
|
Operater Power
|
5-8Kw
|
7-10Kw
|
10-12Kw
|
10-12Kw
|
|||
|
Power Supply
|
3P5W, 380V AC±10%, 50/60HZ
|
|
|
|
|||
|
Dimension
|
L1850*W1850*H1650mm
|
L2600*W1850*H1650mm
|
L2600*W1850*H1650mm
|
|
|||
|
Weight
|
Approx: 800kg
|
Approx: 1800kg
|
Approx: 1900kg
|
Approx: 1900kg
|
|||
Certifications
Packing & Delivery
※ Standard Wooden Case with Vacuum Package
Shipping Way:
※ By air, for sample and small package, international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.
Delivery Time:
※ Within 35 Days.
※ By air, for sample and small package, international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.
Delivery Time:
※ Within 35 Days.
Our Company
About I.C.T：
I.C.T is a leading provider of factory planning solution. we have 3 wholly-owned factories, providing professional consultation and services for global customers. We have more than 22 years of electronic industry experience, through our superior resources in China to provide global customers with systematic overall solutions. We not only provide a complete set of equipment, but also provide full range of technical support and services, and give customers more reasonable professional advice. We help many customers to set up factories in LED, TV, mobile phone, DVB, EMS and other industries all over the world. We are trustworthy.
Exhibition
Customers' Feedback
Related Products
FAQ
|
Q: What we can do for you?
A: One-stop SMT Solution Supplier; Reliable SMT Partner |
|
Q: Are you a trade company or manufacturer?
A: Full SMT machines maufacturer for smt line in China; OEM & ODM service are available. |
|
Q: What is your delivery date?
A: About 35 days after receipt of payment. |
|
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment. |
|
Q: What your main customers?
A: Huawei, Foxconn, Vtech, Sumida, Kemet, Vishay, Bosch, Canon, Jabil etc. |
|
Q: Why choose you?
A: Leading SMT Supplier in China; Professional Supplier on Alibaba; Trade assurance to USD 560,000+; Professional after-sales service team. |
