Quick Details
-
Core:
-
1 2 4 6 8 12 core
-
Product name:
-
self supporting drop wire cable
-
Application:
-
indoor drop cable
-
Length:
-
1km 2km 1000m 2000m
-
Fiber Type:
-
G652D/G657A1/G657A2
-
Name:
-
FRP kfrp ftth drop cable
-
Fiber count:
-
drop 1fo 2c fiber cable
-
Model:
-
kabel fiber optik 1core 3seling
-
Cable type:
-
fiber optic 2 core 3 steel
Quick Details
-
Brand Name:
-
ZR cable
-
Model Number:
-
kabel fiber optik 1 core 1 seling
-
Place of Origin:
-
Hunan, China
-
Core:
-
1 2 4 6 8 12 core
-
Product name:
-
self supporting drop wire cable
-
Application:
-
indoor drop cable
-
Length:
-
1km 2km 1000m 2000m
-
Fiber Type:
-
G652D/G657A1/G657A2
-
Name:
-
FRP kfrp ftth drop cable
-
Fiber count:
-
drop 1fo 2c fiber cable
-
Model:
-
kabel fiber optik 1core 3seling
-
Cable type:
-
fiber optic 2 core 3 steel
Products Description
outdoor kabel serat optik dropcore 1 2 core fibra optica 4 hilo single core 2cores 1f G657A1 fiber optic wire ftth drop cable
Description:
The optical fiber unit is positioned in the centre.
Two parallel FRP or steel wire are placed at the two sides.
steel wire or FRP as the additional strength member is also applied.
Then the cable is completed with a black or color LSZH sheath.
Characteristics:.
1.Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.
2.Two parallel Steel wire or frp strength members ensure good performance of crush resistance to protect the fiber.
3.Single steel wire or messengers as the additional strength member ensures good performance of tensile strength.
4.Simple structure, light weight and high practicability.
5.Novel flute design, easily strip and splice, simplify the installation and maintenance.
6.Low smoke, zero halogen and flame retardant sheath.
Good mechanical and environmental characteristics
Flame retardant characteristics meets the requirements of relevants standards
The mechanical characteristics meets the requirements of relevants standards
Soft, flexible, easy to splice, and with big capacity data transmission
Meet various requirements of market and clients
2.Two parallel Steel wire or frp strength members ensure good performance of crush resistance to protect the fiber.
3.Single steel wire or messengers as the additional strength member ensures good performance of tensile strength.
4.Simple structure, light weight and high practicability.
5.Novel flute design, easily strip and splice, simplify the installation and maintenance.
6.Low smoke, zero halogen and flame retardant sheath.
Good mechanical and environmental characteristics
Flame retardant characteristics meets the requirements of relevants standards
The mechanical characteristics meets the requirements of relevants standards
Soft, flexible, easy to splice, and with big capacity data transmission
Meet various requirements of market and clients
|
Fiber Type
|
Attenuation
|
|
Overfilled launch Bandwidth
|
Effective Modal Bandwidth
|
10GB/S Ethernet link length
|
Min Bending Radius
|
|
|
Conditions
|
1310/1550nm
|
850/1300nm
|
850/1300nm
|
850nm
|
850nm
|
|
|
|
Unit
|
dB/km
|
dB/km
|
MHZ.km
|
MHZ.km
|
m
|
mm
|
|
|
G652D
|
0.36/0.22
|
|
|
|
|
16
|
|
|
G657A1
|
0.36/0.22
|
|
|
|
|
10
|
|
|
G657A2
|
0.36/0.22
|
|
|
|
|
7.5
|
|
|
50/125
|
|
3.0/1.0
|
≥500/500
|
|
|
30
|
|
|
62.2/125
|
|
3.0/1.0
|
≥200/500
|
|
|
30
|
|
|
OM3
|
|
3.0/1.0
|
≥1500/500
|
≥2000
|
≥300
|
30
|
|
|
OM4
|
|
3.0/1.0
|
≥3500/500
|
≥4700
|
≥550
|
30
|
|
|
B1-OM3
|
|
3.0/1.0
|
≥1500/500
|
≥2000
|
≥300
|
7.5
|
|
|
B1-OM4
|
|
3.0/1.0
|
≥3500/500
|
≥4700
|
≥550
|
7.5
|
|
Technical parameter for steel wire drop cable
|
Cable code
|
FIiber count
|
Cable size
(mm) |
Cable weight
(KG/KM) |
Tensile strength long/short
term(N) |
Crush resistance
long/short term (N/100mm) |
Bending radius
static/dynamic (mm) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GJYXCH
|
1
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXCH
|
2
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXCH
|
4
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXCH
|
8
|
(2.5+-0.1)X(6.0+-0.1)
|
27
|
300/600
|
1100/2200
|
15/30
|
|
GJYXCH
|
12
|
(2.5+-0.1)X(6.0+-0.1)
|
27
|
300/600
|
1100/2200
|
15/30
|
Technical parameter for FRP drop cable
|
Cable code
|
FIiber count
|
Cable size
(mm) |
Cable
weight (KG/KM) |
Tensile strength
long/short term (N) |
Crush resistance
long/short term (N/100mm) |
Bending radius
static/dynamic (mm) |
|
GJYXFCH
|
1
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXFCH
|
2
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXFCH
|
4
|
(2.0+-0.1)X(5.2+-0.1)
|
19
|
300/600
|
1100/2200
|
15/30
|
|
GJYXFCH
|
8
|
(2.5+-0.1)X(6.0+-0.1)
|
27
|
300/600
|
1100/2200
|
15/30
|
|
GJYXFCH
|
12
|
(2.5+-0.1)X(6.0+-0.1)
|
27
|
300/600
|
1100/2200
|
15/30
|
