Quick Details
-
Warranty:
-
25 year
-
Brand Name:
-
Suntop
-
Model Number:
-
AA01
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
541 x 676 x 35 mm
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction box:
-
IP 68 rated
-
Weight:
-
4.6kg
-
Certificate:
-
CE-RoHS
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black
-
Panel Efficiency:
-
150w-200w, 13.7%
-
Warranty:
-
25 year
-
Brand Name:
-
Suntop
-
Model Number:
-
AA01
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
541 x 676 x 35 mm
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction box:
-
IP 68 rated
-
Weight:
-
4.6kg
-
Certificate:
-
CE-RoHS
Product Description
Specification
|
Module
|
SPxxxM-36 xxx = Peak Power Watts
|
|
|
|
|
||||
|
Peak Power Watts(Pmax/W)
|
10
|
20
|
30
|
40
|
50
|
||||
|
Power Output Tolerance(W)
|
+3%
|
|
|
|
|
||||
|
Maximum Power Voltage(Vmp/V)
|
17.9
|
17.88
|
17.9
|
18.1
|
18.32
|
||||
|
Maximum Power Current(Imp/A)
|
0.56
|
1.12
|
1.68
|
2.21
|
2.73
|
||||
|
Open Circuit Voltage(Voc/V)
|
22
|
22.2
|
22.37
|
22.62
|
22.8
|
||||
|
Short Circuit Current(Isc/A)
|
0.62
|
1.24
|
1.68
|
2.48
|
2.93
|
||||
|
Module Efficiency(%)
|
10.07
|
11.6
|
12.5
|
12.4
|
13.7
|
||||
|
Module
|
SPxxxP-36 xxx = Peak Power Watts
|
|
|
|
|
||||
|
Peak Power Watts(Pmax/W)
|
20
|
30
|
40
|
50
|
55
|
||||
|
Power Output Tolerance(W)
|
3%
|
|
|
|
|
||||
|
Maximum Power Voltage(Vmp/V)
|
17.2
|
17.3
|
17.3
|
17.5
|
18.18
|
||||
|
Maximum Power Current(Imp/A)
|
1.17
|
1.77
|
2.31
|
2.9
|
3.1
|
||||
|
Open Circuit Voltage(Voc/V)
|
21.7
|
21.9
|
21.8
|
21.8
|
22.1
|
||||
|
Short Circuit Current(Isc/A)
|
1.25
|
1.93
|
2.54
|
3.2
|
3.31
|
||||
|
Module Efficiency(%)
|
10.3
|
10.9
|
11.5
|
11.2
|
13.2
|
||||
Glass by
XINYI,SG CNBM
Anti-reflective glass
22% Higher Efficiency Cell
by
Tier 1 Brand
Frame by Tentop(Black/Silver Optional)
120N
Tensile Strength Frame
Waterproof Labels Product by Waterproof Labels Suntop/OEM
Juction Boxes
by TL, QC
SolarInnovative Full-Glue-Filled
IP68
Waterproofness
PV Connector by
TL, QC Solar
MC4 4mm Qualified cable
