Quick Details
-
Control System Brand:
-
RuiDa
-
Cutting Area:
-
1600*1000mm
-
Cutting Thickness:
-
0-20mm
-
Control Software:
-
DSP
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
FST
-
Weight (KG):
-
410 KG
-
Core Components:
-
laser power
-
Product name:
-
fabric cloth textile cutting machine
-
Keyword:
-
textile cutting machine
-
Laser power:
-
80w/100w/130w/150w
-
Cutting materials:
-
Fabric Cutting Table Industrial
-
Laser type:
-
sealed co2 glass laser tube
-
Cutting thickness:
-
0-20mm ( depends on materials)
-
Resolution rate:
-
±0.05mm
-
Working voltage:
-
220v±10% 50hz 110v±10%60hz
-
Supported graphic formats:
-
BMP PCX TGA TIF PLT CDR
-
Working temperature:
-
0-45°C
Quick Details
-
Laser Type:
-
CO2
-
Cutting Speed:
-
2400mm/min
-
Cooling Mode:
-
WATER COOLING
-
Control System Brand:
-
RuiDa
-
Cutting Area:
-
1600*1000mm
-
Cutting Thickness:
-
0-20mm
-
Control Software:
-
DSP
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
FST
-
Weight (KG):
-
410 KG
-
Core Components:
-
laser power
-
Product name:
-
fabric cloth textile cutting machine
-
Keyword:
-
textile cutting machine
-
Laser power:
-
80w/100w/130w/150w
-
Cutting materials:
-
Fabric Cutting Table Industrial
-
Laser type:
-
sealed co2 glass laser tube
-
Cutting thickness:
-
0-20mm ( depends on materials)
-
Resolution rate:
-
±0.05mm
-
Working voltage:
-
220v±10% 50hz 110v±10%60hz
-
Supported graphic formats:
-
BMP PCX TGA TIF PLT CDR
-
Working temperature:
-
0-45°C
Product description
Application Industry
Product Paramenters
|
Model
|
FST-1610
|
|
|
Working area
|
1600*1000mm
|
|
|
Laser type
|
sealed co2 glass laser tube
|
|
|
Laser power
|
60W/80W/100W/150W/180W/300W/600W (Optional)
|
|
|
Engraving speed
|
0-1500mm/s
|
|
|
Cutting speed
|
0-400mm/s
|
|
|
Cutting thickness
|
0-30mm ( depends on materials)
|
|
|
Resolution rate
|
±0.05mm
|
|
|
Data transfer interface
|
USB2.0
|
|
|
Working voltage
|
220v±10% 50hz 110v±10%60hz
|
|
|
Up and down worktable
|
Up and down 550mm adjustable
|
|
|
Software
|
RdworksV8/ CorelDraw/AutoCAD
|
|
|
Working table
|
honeycomb or aluminum knife
|
|
|
Supported graphic formats
|
BMP PCX TGA TIF PLT CDR
|
|
|
Working temperature
|
0-45°C
|
|
|
Working humidity
|
5%-90%
|
|
|
Rsolution ratio
|
<4500DPI
|
|
|
Applicable materials
|
Fabric, leather etc Fexible material
|
|
|
Package
|
Packing in export wooden cases
|
|
|
Assistant Equipment
|
water chiller/ Exhaust Fan / Air Pump
|
|
|
The above parameters are la boratory test results, subject to actual operating conditions.
|
|
|
Details Images
Main configuration
Product packaging
