- Product Details
- {{item.text}}
Quick Details
-
Power (kW):
-
15
-
Range of Spindle Speed(r.p.m):
-
2800 - 4500 r.p.m
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LONGER Tea Leaf Coffee Mini Grinding Machine
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
800*950*1550mm
-
Weight (KG):
-
660 KG
-
Marketing Type:
-
New Product
-
Machine Type:
-
Spice Pulverizer Machine
-
Keywords:
-
Industrial Coffee Grinding Machine
-
Grinding size:
-
60-120 mesh
-
Revolution of spindle:
-
2800r/min Spice Grinding Machines
-
After Warranty Service:
-
Field maintenance and repair service
-
Local Service Location:
-
Viet Nam
-
Certification:
-
ISO CE Tea Leaf Coffee Mini Grinding Machine
Quick Details
-
Output (kg/h):
-
200 - 500 kg/h
-
Feeding Size (mm):
-
1 - 50 mm
-
Output Size (mesh):
-
20 - 120 mesh
-
Power (kW):
-
15
-
Range of Spindle Speed(r.p.m):
-
2800 - 4500 r.p.m
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LONGER Tea Leaf Coffee Mini Grinding Machine
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
800*950*1550mm
-
Weight (KG):
-
660 KG
-
Marketing Type:
-
New Product
-
Machine Type:
-
Spice Pulverizer Machine
-
Keywords:
-
Industrial Coffee Grinding Machine
-
Grinding size:
-
60-120 mesh
-
Revolution of spindle:
-
2800r/min Spice Grinding Machines
-
After Warranty Service:
-
Field maintenance and repair service
-
Local Service Location:
-
Viet Nam
-
Certification:
-
ISO CE Tea Leaf Coffee Mini Grinding Machine
Industrial Herbal Medicine Powder Grinding Machines Spices Tea Leaf Coffee Mini Grinding Machine
|
Product Description of Mini Grinding Machine: |
Good Quality Automatic Spice Turmeric Powder Grinder Pulverizer Machine Price Spice Grinding Machines
Motion of the Mini Grinding Machine movable disc and the fixed tooth disk is used to crush the crush of the crushed material through the tooth impact, friction and the impact of the material.
This machine of simple structure, strong, stable operation, crushing effect is good, the crushed material can directly by the host grinding cavity vent, the particle size can be obtained by changing different aperture of mesh, while the machine for stainless steel.
|
Application Of Herbal Medicine Grinding Machines: |
Herbal Grinding Machines for tangential feed hammer type crusher that can crush all kinds of dry feed, such as corn, sorghum, rice straw, wheat straw, potato vine, corn stalk, peanut vine, bean pole, etc., can also be crushed, quartz, coal, wood raw materials.
|
Working Principle of Industrial Coffee Grinding Machine: |
By using the Industrial Coffee Grinding Machine relative high-speed operation between the movable disc and the fixed gear disc, the crushed objects are crushed by the impact, friction and material collision of the disc.The material can be directly from the eduction in grinding chamber, the discharging mouth out, after crushing material into the bag collection, shredded material collected in the bag, the air out of a bag of tiny hole, will not be fine powder, thereby not waste, no pollution effect.
|
Parameter of Mini Grinding Machine: |
|
Model |
LG-20B-C |
LG-30B-C |
LG40B-C |
LG60B |
|
Capacity(kg/h) |
60-150kg/h |
100-300kg/h |
160-800kg/h |
500-1500kg/h |
|
Revolution of spindle |
4500r/min |
3800r/min |
3400r/min |
2800r/min |
|
Size of fed material (mm) |
6 |
10 |
12 |
15 |
|
Grinding size |
60-120 mesh |
|||
|
Crusher motor |
4kw |
5.5kw |
11kw |
15kw |
|
Cleaner motor |
0.75kw |
|||
|
Dimension (mm) |
550*600*1250 |
600*700*1450 |
800*900*1550 |
1000*900*1680 |
|
Weight (kg) |
250 |
320 |
550 |
680 |
|
Tips of Mini Grinding Machine: |
1. Different seasons, different temperatures and different water temperatures will produce different cooling effects. Spice Grinding Machines
2. Different materials produce different heat and different temperature.
3. The lower the water temperature, the better the cooling effect. Tea Leaf Coffee Mini Grinding Machine
|
Details Pictures of Mini Grinding Machine |
Other model crusher machine Spice Grinding Machines
Industrial Herbal Medicine Powder Grinding Machines Spices Tea Leaf Coffee Mini Grinding Machine
1. This is my first time to import, how can I trust your company and ensure to get the goods if I order from you? Industrial Herbal Medicine Powder Grinding Machines Spices Tea Leaf Coffee Mini Grinding Machine
We are alibaba legitimate certification company, and we support payment terms: L/C,T/T, Western Union, Alibaba Trade Assurance, to ensure your safety.
2. How do you ensure the quality of your products? Tea Leaf Coffee Mini Grinding Machine
We promise guarantee as one year for non-human damage factor, and whole life online technician service. Industrial Herbal Medicine Powder Grinding Machines Spices Tea Leaf Coffee Mini Grinding Machine
3. How do you ship the machine? Tea Leaf Coffee Mini Grinding Machine
Usually we supply Bill of Lading(Telex Released), Packing List and Invoice freely. If you need original document, we can send by express. And can supply other documents as customers demand, like CE, CO etc. Tea Leaf Coffee Mini Grinding Machine
4. What voltage of your machine? Herbal Medicine Powder Grinding Machines Spices Tea Leaf Coffee Mini Grinding Machine
We normally make it 220V/50Hz/Single Phase or 380V/50Hz/Three Phases. But it can be made accourding to clients' demand, like 110V/60Hz/Single Phase, 400V/50Hz/Three Phases etc.
1.Our company usually packs in standard export wooden case. Tea Leaf Coffee Mini Grinding Machine
2.Transportation means by Air, by Sea or by Express and ect. Tea Leaf Coffee Mini Grinding Machine
3.Shipment cost will depend on the destination, shipment wayand the weight of the goods.
4.You will get full feedback when your machine is on the way. Spice Grinding Machines
