Quick Details
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
MDY500 CE standard power operate 500 ton hydraulic press
-
Model:
-
MDY500
-
Nominal pressure:
-
5000kN
-
Hydraulic pressure:
-
30MPa
-
Stroke of cylinder rod:
-
350mm
-
Working speed:
-
K12.2/M2.7/H19.9 mm/s
-
Size of worktable:
-
1190*760/180mm diameter hole
-
Distance between column:
-
1250mm
-
Open height:
-
893mm
-
Pump station:
-
900*550mm
-
Weight:
-
5700kg
-
Certification:
-
CE ISO
-
Power:
-
(variable pump station)
Quick Details
-
Place of Origin:
-
Shandong, China
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
MDY500 CE standard power operate 500 ton hydraulic press
-
Model:
-
MDY500
-
Nominal pressure:
-
5000kN
-
Hydraulic pressure:
-
30MPa
-
Stroke of cylinder rod:
-
350mm
-
Working speed:
-
K12.2/M2.7/H19.9 mm/s
-
Size of worktable:
-
1190*760/180mm diameter hole
-
Distance between column:
-
1250mm
-
Open height:
-
893mm
-
Pump station:
-
900*550mm
-
Weight:
-
5700kg
-
Certification:
-
CE ISO
-
Power:
-
(variable pump station)
MDY500 CE standard power operate 500 ton hydraulic press
MDY500 is a power operate 500 ton hydraulic press with Advanced equipments and CE standard.
Main Features:
1.It adopts an elaborated steel frame structure, a column with a work bench beam, a sliding rail and a rear protective net.
2.The good quality of the products is based on exquisite manufacturing process and durable parts and components.
3.Its double-action cylinder, which is the original component of sound hydraulic systems, can stand wear and tear.
4.It is equipped with a soft starter and a manual stroke controller to control upward and downward movement of the piston rod, which is very sage and convenient.
5.The lower workbench beam is equipped with a set of specialized sling and sliding rail, which is labor-saving, safe and convenient.
6.Suitable for general mechanical parts assembling and disassembling.
Detailed specifications of MDY500 CE standard power operate 500 ton hydraulic press:
| Model | Unit | MDY500/35 |
| Nominal pressure | KN | 5000 |
| Hydraulic pressure | Mpa | 30 |
| Stroke of cylinder rod | mm | 350 |
| Working speed | mm/s | K12.2/M2.7/H19.9 |
| Size of worktable | mm | 1190*760mm/180mm hole dia. |
| Adjustment distance of worktable | mm*n | FIXED |
| Motor power | kw | 116 15 variable pump station |
| Size techinal parameter | ||
| A | mm | 1810 |
| B | mm | 1250 |
| C | mm | 2680 |
| D | mm | 1250 |
| E | mm | 893 |
| I | mm | 750 |
| Pump station | 900*550mm | |
| Pump station model | YBZ116 | |
| Packing size | mm | 2750*1300*2050mm |
| N.W./G.W. | kg | 5700/5820 |
Standard accessoires :
1) Full -c losed side plate,
2)Back protection cover,
3)Beam of workplatform,
4)High quality boring/grinding cylinder,
5) Grade A sealing element,
6)Worktable plate,and V-shap iron 2 pieces
7) 5μm Piston rod chromium plating laye,
8)Accuracy: 30μm
9) SIEM ENS motor.
10)with CE standard (24V low voltage control, open the door off, SCHNEIDER electric power unit)
11)One set special sling
12) REXROTH hydraulic and valve
You can find more detailed pictures of our MDY500 CE standard power operate 500 ton hydraulic press as following:
MDY500 CE standard power operate 500 ton hydraulic press
Packing size: press machine body: 2750*1300*2050mm, pump station: 950*600*1450mm
Standard package is pallet
We also would like to let you know our warranty about our MDY500 CE standard power operate 500 ton hydraulic press.
==about the machine break down, normally our policy will be as the under way
1) Our quality guarantee time is 12 months since the machine on board
2) During this period, if the machine break down owing our machine itself quality problem, we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
3) If the break down is caused by the mis operation, we of course will supply you the spare parts, but we have to charge you the costs prices.
