- Product Details
- {{item.text}}
Quick Details
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
AQUA
-
Year:
-
2019
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
1750*670*1860mm
-
Hollow part volume:
-
2L
-
Clamping Force (kN):
-
400
-
Power (kW):
-
26KW
-
Weight (KG):
-
1200 KG
-
Automatic:
-
Yes
-
Keywords:
-
bottle blowing machine
-
Capacity:
-
800-14000pcs/h
-
Quality:
-
High
-
Cavity:
-
2 cavity / 4 cavity / 6 cavity /8 cavity / 9 cavity
-
Full automatic grade:
-
Full automatic and semi automatic
-
bottle volume:
-
0.1-2L
-
raw material:
-
PET preform
-
machine type:
-
stretch type blowing machine
-
Power:
-
17.5kw
-
Marketing Type:
-
2022
Quick Details
-
Neck Diameter(mm):
-
39 mm
-
Max.Bottle Diameter(mm):
-
90 mm
-
Max.Bottle Height(mm):
-
320 mm
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
AQUA
-
Year:
-
2019
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
1750*670*1860mm
-
Hollow part volume:
-
2L
-
Clamping Force (kN):
-
400
-
Power (kW):
-
26KW
-
Weight (KG):
-
1200 KG
-
Automatic:
-
Yes
-
Keywords:
-
bottle blowing machine
-
Capacity:
-
800-14000pcs/h
-
Quality:
-
High
-
Cavity:
-
2 cavity / 4 cavity / 6 cavity /8 cavity / 9 cavity
-
Full automatic grade:
-
Full automatic and semi automatic
-
bottle volume:
-
0.1-2L
-
raw material:
-
PET preform
-
machine type:
-
stretch type blowing machine
-
Power:
-
17.5kw
-
Marketing Type:
-
2022
Stable Quality Small Water Bottle Manufacturing Plant Making Plant / Bottle Blowing Machine
1. It is used to make PET bottles
2. we have different capacity blowing machine from 600-14000pcs.h, tell me your requirement, so we can give the solution.
3. For 0.1-20L bottle size .
4. water bottle, carbonated bottle can use the same machine, juice machine will be different. so customers should be clear.
Recently we shipped a 7000bph bottle blowing machine, here share some pictures for reference
Main electic Component of our Bottle Blowing Machine
|
Electrical components |
PLC |
Taiwan Delta |
Cylinders |
clamping cylinder |
SMC |
|
touch screen |
Taiwan Delta |
stretching cylinder |
SMC |
||
|
relay |
Schneider |
bottle-takeout flipping cylinder |
FEST0 |
||
|
circuit breaker |
Schneider |
first-stage slide cylinder |
SMC |
||
|
air switch |
Schneider |
second-stage slide cylinder |
SMC |
||
|
start button |
Schneider |
heating cylinder |
SMC |
||
|
two-position switch |
Schneider |
Preform-separating cylinder |
SMC |
||
|
scram button |
Schneider |
Manipulator cylinder |
SMC |
||
|
power supply |
Schneider |
Bottle die cylinder |
SMC |
||
|
proximity switch |
Schneider |
Valves |
high pressure blowing valve |
PARKER |
|
|
photoelectric switch |
Schneider |
high pressure exhaust valve |
PARKER |
||
|
Air Filtration |
low pressure oil-water separator |
FEST0
3 in 1 |
high pressure one-way valve |
FEST0 |
|
|
low pressurepress-regulating valve |
low pressure muffler |
SMC |
|||
|
low pressure lubricator |
high pressure muffler |
ALWITCO |
|||
Technicial Parameters of Bottle Making Machine
|
Item |
Technical Parameters |
|
|
Product Specifications |
Max Volume |
1800ml |
|
Max.container diameter |
Φ105 |
|
|
Max Container Mouth diameter |
Φ18mm - 38mm |
|
|
Max.container diameter |
330mm |
|
|
Max. Preform height embryonic tube |
180mm |
|
|
Clamping stroke |
120mm |
|
|
Base mould stroke |
50mm |
|
|
Bottle Spacing |
114.3mm |
|
|
Standard thickness of mold |
220mm |
|
|
Capacity |
4000 ( 500ml ) |
|
|
Mould |
4 |
|
|
Heating Part |
Heating Unit |
5 |
|
Heating lamp laye |
9 |
|
|
Number of tubules |
80 |
|
|
Machine Power |
Voltage |
220/380V |
|
Frequency |
50/60Hz |
|
|
Power |
35kw/h |
|
|
Installed power |
75kw |
|
|
Air Source |
High pressure compressed air pressure |
25~30bar |
|
High pressure compressed air consumption |
3.0m3/min |
|
|
Water chiller |
Pressure |
3bar |
|
Chilled water yield |
5m3/h |
|
|
Weight |
Main machine \ Heating machine \ electric control box |
3.5T |
|
Machine Size |
Machine (L×W×H) |
4500mm×2200mm×2300mm |
|
Preform-loader(L×W×H) |
2000mmx1400mm×2500mm |
