Quick Details
-
Warranty:
-
10YEARS
-
Model Number:
-
HS-M166H672 440-460W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Junction Box:
-
IP68
-
cable:
-
4mm²/300mm
-
Frame:
-
Anodized aluminum alloy
-
Tempered Glass:
-
3.2mm High Permeability Coated
-
Module per box:
-
31Pcs
-
Voltage at Pmax:
-
42.8V
-
Current at Pmax:
-
10.75A
-
Open Circuit Voltage:
-
50.42V
-
Short Circuit Current:
-
11.26A
-
40':
-
682Pcs
-
Certificate:
-
CE,TUV
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC, Half Cell, Double-glass, TOPCON
-
Panel Efficiency:
-
21.2%
-
Warranty:
-
10YEARS
-
Model Number:
-
HS-M166H672 440-460W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Junction Box:
-
IP68
-
cable:
-
4mm²/300mm
-
Frame:
-
Anodized aluminum alloy
-
Tempered Glass:
-
3.2mm High Permeability Coated
-
Module per box:
-
31Pcs
-
Voltage at Pmax:
-
42.8V
-
Current at Pmax:
-
10.75A
-
Open Circuit Voltage:
-
50.42V
-
Short Circuit Current:
-
11.26A
-
40':
-
682Pcs
-
Certificate:
-
CE,TUV
|
Liectrical Parameters at （STC）
|
|
|
Power
|
440W 445W 450W 455W 460W
|
|
Module Efficiency
|
20.3% 20.5% 20.7% 20.9% 21.2%
|
|
Voltage at Pmax（Vmp）
|
41.40 41.75 42.10 42.45 42.80
|
|
Current at Pmax（Imp）
|
10.63 10.66 10.69 10.72 10.75
|
|
Open Circuit Voltage（Voc）
|
49.25 49.55 49.84 50.13 50.42
|
|
Short Circuit Current（Isc）
|
11.134 11.17 11.20 11.23 11.26
|
|
|
|
|
Mechanical Parameters
|
|
|
Solar Cell（Type/Size）
|
Mono(166mm)
|
|
Solar Cells Number
|
144Pcs(6*24)
|
|
Dimension
|
2094*1038*35mm
|
|
Weight
|
24.30KG/Pcs
|
|
Tempered Glass
|
3.2mm High Permeability Coated
|
|
Junction Box
|
IP68
|
|
Cable
|
4.0mm²/300mm
|
|
Connector
|
MC Compatible
|
|
Mechanical Load
|
Front 5400PA/back 2400PA
|
|
|
|
|
Packing
|
|
|
Module per box
|
31 Pcs
|
|
40' Container
|
682 Pcs
|
