Quick Details
-
Main structure:
-
Cold-formed steel framing
-
Exterior Wall Cladding:
-
Reachfly Panel
-
Life Span:
-
50 Year Plus
-
Style:
-
Steel Prefab House
-
Usage:
-
2 Floor Prefab House
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Reachfly
-
Model Number:
-
Rf-h
-
Main structure:
-
Cold-formed steel framing
-
Exterior Wall Cladding:
-
Reachfly Panel
-
Life Span:
-
50 Year Plus
-
Style:
-
Steel Prefab House
-
Usage:
-
2 Floor Prefab House
|
Items
|
Specifications
|
|
|
||
|
Framing
|
G550 Light Gauge Steel, Thickness of 0.8-1.2mm, Zinc Coating 150g/m
2
|
|
|
||
|
Wall System
|
Exterior - OSB Boards + Breathing Paper + Exterior Wall Panels
Middle - Light Steel Frame with Mineral Wool Inside Interior - OSB Boards + Gypsum Boards |
|
|
||
|
Roofing
|
Asphalt Shingles / Metal Roof
|
|
|
||
|
Floor
|
Concrete + Customized Finishing
|
|
|
||
|
Windows
|
Aluminum Sliding Windows, Single or Double Glass
|
|
|
||
|
Door
|
Wooden door, Security Door, Aluminum Door
|
|
|
||
|
Bathroom
|
Shower, Seated Toilet, Wash Basin, Towel Rack
|
|
|
||
|
Plumbing
|
PPR and PVC water supply and drainage pipe with fittings
|
|
|
||
|
Electrical System
|
Wires, fittings and lights can be provided as per customer's request
|
|
|
||
|
Technical Data of Reachfly Light Steel Prefab Houses
|
|
|
|
|||
|
Roof load
|
≧50kilograms/m
2
|
|
|
|||
|
Flooring load
|
≧150kilograms/m
2
|
|
|
|||
|
Fire proof
|
Can up to A grade or B grade
|
|
|
|||
|
Seismic grade
|
9-magnitude
|
|
|
|||
|
Wind loading
|
11 level of wind loading
|
|
|
|||
|
Residential buildings
|
Commercial buildings
|
Institutional buildings
|
Booths
|
|
*cabins
*bungalows
*townhouses
*vacation houses
*two-storey houses/villas
|
*hotels
*resorts
*offcies
*showrooms
*4s car shops
*supurmarkets
*accommodation
|
*schools
*hospitals
*medical clinics
*health-care centers
|
*guardhouses
*public toilets
parking lot kiosks
|
1. Why build with steel frame?
Materials of metal frames are economical, lightweight and easy to handle. Galvanized Steel will not crack, shrink, splinter, creep, split, warp, swell or rot. Steel is impervious to termites and wood destroying insects.
2. How is a steel house insulated?
In order to combat the conductivity of the steel, the recommended procedure is to install a polyurethane foam board on the exterior of your frame. This will make sure that there is no heat transferred directly to the steel. We offer Reachfly wall panels and extra insulation boards to cover the temperature of most areas.
3. How well does steel framing stand up to earthquakes or hurricanes?
Light gauge steel framed house can be engineered to meet the highest seismic and wind loads required in most of the areas. Steel has the highest strength to weight ratio of any framing materials and a lighter structure with stronger connections results in lower damage from earthquakes. Steel framed houses in hurricanes suffered only superficial but no structural damage. Stronger connections by screws can withstand greater winds including cyclones or hurricanes.
4. Can you build multi-story buildings with cold-framed steel?
From an engineering point of view, steel framing with current technology and detailing can go up to three or four stories although most residential buildings are limited to two stories.
5. Do steel framed homes have to be built on piles or concrete slabs?
Either. Steel frames can be fixed to a concrete slab or fixed to a lightweight steel floor system on concrete or steel piles. Lightweight steel flooring systems are ideal for elevated or sloping sites as they can minimize foundation requirements.
