Quick Details
-
Brand Name:
-
GUBANG
-
Model Number:
-
SPC-PP 315W-330W
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Cell Type:
-
Polycrystalline 60pcs
-
Weight:
-
27
-
Dimensions:
-
1956*992*40mm
-
Cable Length(mm):
-
≥1000
-
Cable cross section size(mm²):
-
4
-
Junction Box:
-
IP68Rated
-
Packing configuration:
-
26pcs/carton
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
PERC
-
Warranty:
-
25YEARS
-
Brand Name:
-
GUBANG
-
Model Number:
-
SPC-PP 315W-330W
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Cell Type:
-
Polycrystalline 60pcs
-
Weight:
-
27
-
Dimensions:
-
1956*992*40mm
-
Cable Length(mm):
-
≥1000
-
Cable cross section size(mm²):
-
4
-
Junction Box:
-
IP68Rated
-
Packing configuration:
-
26pcs/carton
|
ELECTRICAL PARAMETERS AT STC
|
|
|
|
|
||||
|
Type
|
SPC-PP315W
|
SPC-PP320W
|
SPC-PP325W
|
SPC-PP330W
|
||||
|
Rated Maximum Power(Pmax)[W]
|
315
|
320
|
325
|
330
|
||||
|
Maximum Power Voltage(Vmp)
|
37.1V
|
37.4V
|
37.6V
|
37.8V
|
||||
|
Maximum Power Current(Imp)
|
8.51A
|
8.56A
|
8.65A
|
8.74A
|
||||
|
Open-Circuit Voltage Voc(V)
|
45.4V
|
45.6V
|
45.9V
|
46.2V
|
||||
|
Short-Circuit Current Isc(A)
|
9.09A
|
9.1A
|
9.16A
|
9.24A
|
||||
|
Module Eficiency [%]
|
16.23
|
16.49
|
16.75
|
17.01
|
||||
|
Power Current
|
0 ~ +3%
|
|
|
|
||||
|
a Isc
|
+0.04%/℃
|
|
|
|
||||
|
B Voc
|
－0.30%/℃
|
|
|
|
||||
|
y Pmp
|
-0.40%/ C
|
|
|
|
||||
|
STC
|
Irradiance 1000W/m²,cell temperature 25℃,AM1.5G
|
|
|
|
||||
