Quick Details
-
Power:
-
120kw
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
EON
-
Maximum Digging Height:
-
10,918mm
-
Maximum Digging Depth:
-
6,439mm
-
Machine Weight:
-
18000 kg
-
Max Digging Radius:
-
3,011mm
-
Marketing Type:
-
New Product 2023
-
Service Provided:
-
Engineers available to service machinery overseas
-
Arm length:
-
3400mm
-
Boom length:
-
5500mm
-
amphibious excavator:
-
amphibious excavator
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Argentina
-
After-sales Service Provided:
-
Field installation, commissioning and training
Quick Details
-
Operating Weight:
-
15000kg
-
Bucket capacity:
-
1.0m3
-
Engine Brand:
-
top brand
-
Power:
-
120kw
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
EON
-
Maximum Digging Height:
-
10,918mm
-
Maximum Digging Depth:
-
6,439mm
-
Machine Weight:
-
18000 kg
-
Max Digging Radius:
-
3,011mm
-
Marketing Type:
-
New Product 2023
-
Service Provided:
-
Engineers available to service machinery overseas
-
Arm length:
-
3400mm
-
Boom length:
-
5500mm
-
amphibious excavator:
-
amphibious excavator
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Argentina
-
After-sales Service Provided:
-
Field installation, commissioning and training
15 ton amphibious excavator swamp excavator HK150SD
Specifications:
1)Japan engine
2)Power:86.5kW
3)Bucket capacity: 1.0m3
o Engine:
§ Name: Japanese engine
§ Model: 4BG1
§ Type: turbo-charged
§ Power: 86.5kW/2,200rpm
§ Maximum torque: 449Nm at 1,800rpm
§ Number of cylinders: 4
§ Displacement: 4.329L
o Standard bucket capacity: 0.4m3
o Arm length: 3,400mm
o Boom length: 5500mm
o Chain: 2 chains
o Tank capacity:
§ Fuel tank capacity: 217L
§ Hydraulic tank capacity: 217L
o Working ranges:
§ Maximum digging reach: 9,940mm
§ Maximum digging reach on ground: 9,616mm
§ Maximum digging depth: 6,439mm
§ Maximum vertical wall digging depth: 5,358mm
§ Maximum cutting height: 10,918mm
§ Maximum dumping height: 8,719mm
§ Minimum front slew radius: 3,011mm
o Operating weight: 20,000kg
· Hydraulic system:
o Main pump:
§ Type: variable displacement axial piston pumps
§ Maximum displacement: 2 x 63cm3/r
o Pilot pump:
§ Type: gear pump
§ Working pressure: 30mPa
· Hydraulic motor:
o Slew: fixed displacement axial piston motor
o Travel: variable displacement axial piston motors
· Performance:
o Slew speed: 13.6rpm
o Minimum back slew radius: 2468mm
o Maximum travel speed high/low: 3/2.1kph
o Gradeability: 30 degrees
o Tractive effort: 157.5kN
o Maximum digging force of bucket: 72kN
o Maximum digging force of arm: 51kN
Ground pressure: 0.13kg/cm2
