Quick Details
-
Model Number:
-
K219T
-
Type:
-
Foot Switch Automatic Doors
-
Power:
-
36W
-
Sensing Range:
-
10cm
-
Product name:
-
Automatic Door Opener Feet Sensor Switch Foot Switch
-
Dimensions:
-
186x175x53 mm
-
Output Contact:
-
NC or NO
-
Sensor Distance:
-
5-8cm
-
Operating temp:
-
-20℃~+55℃(14-131F)
-
Suitable Humidity:
-
0-95% (relative humidity)
-
Suitable for Door:
-
Hollow Door
-
Detection mode:
-
Truncation of infrared ray by foot operated to produce the open signal
-
Mechanical Life:
-
1000000 tested
-
Recommend installation height:
-
0.3 meter height from the ground
-
Certification:
-
CE
Quick Details
-
Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ACM
-
Model Number:
-
K219T
-
Type:
-
Foot Switch Automatic Doors
-
Power:
-
36W
-
Sensing Range:
-
10cm
-
Product name:
-
Automatic Door Opener Feet Sensor Switch Foot Switch
-
Dimensions:
-
186x175x53 mm
-
Output Contact:
-
NC or NO
-
Sensor Distance:
-
5-8cm
-
Operating temp:
-
-20℃~+55℃(14-131F)
-
Suitable Humidity:
-
0-95% (relative humidity)
-
Suitable for Door:
-
Hollow Door
-
Detection mode:
-
Truncation of infrared ray by foot operated to produce the open signal
-
Mechanical Life:
-
1000000 tested
-
Recommend installation height:
-
0.3 meter height from the ground
-
Certification:
-
CE
Product Description
Hospital Operating Clean Room Environments AUTO Pedal Inductive Door Opener Feet Sensor Switch Foot Switch
What is Foot Sensor Switch?
Foot switch (photoelectric activation sensor) , fixed on the lower part of the wall (embedded), operated by foot without hand’s touch. Usually it is used in circumstances that direct hand touch is not allowed to assure environment clean, such as operating clean rooms in hospital and food manufacturing industries.
Features:
With pull in & out socket for easy wiring
Adopt microcomputer control with exquisite design of stainless steel wire cover
Installation with hidden screw hole, easy to be fixed and stable performance
Widely be used in the operating room of hospital and laboratory to prevent hand pollution
Detection mode: Receive the open signal by the truncation of infrared ray which operated by foot
Active infrared ray of modulation-demodulation controlled by microcomputer
What is Foot Sensor Switch?
Foot switch (photoelectric activation sensor) , fixed on the lower part of the wall (embedded), operated by foot without hand’s touch. Usually it is used in circumstances that direct hand touch is not allowed to assure environment clean, such as operating clean rooms in hospital and food manufacturing industries.
Features:
With pull in & out socket for easy wiring
Adopt microcomputer control with exquisite design of stainless steel wire cover
Installation with hidden screw hole, easy to be fixed and stable performance
Widely be used in the operating room of hospital and laboratory to prevent hand pollution
Detection mode: Receive the open signal by the truncation of infrared ray which operated by foot
Active infrared ray of modulation-demodulation controlled by microcomputer
|
Technical measure
|
Active infrared ray of modulation and demodulation
|
|
Recommend installation height
|
0.3m height from the ground
|
|
Detection mode
|
Truncation of infrared ray by foot operated to produce the open signal
|
|
Reaction time
|
Relay output <45ms
|
|
Supply power
|
AC/DC 12~30V
|
|
Stand-by current
|
8.2mA
|
|
Operating current
|
47mA
|
|
Supervisory signal
|
4.5S MA
|
|
Signal output
|
Relay normally open or normally closed
|
|
Operation temperature
|
-20℃~55℃
|
|
Interference immunity
|
Sunlight 81000LUX, incandescent lamp 36000LUX, electronic microwave conforms to 89336CEE standard
|
|
Hole Size
|
130x120x50mm
|
|
Dimension
|
186x175x53mm
|
Detailed Images
Click here to order and have your FREE SAMPLE in 3 days!!!
We are professional comprehensive security access control products supplier with 20 years experience, we make sure to offer the best solution of access control system solution! So, send your inquiry details in the below, click "Send" now!
We are looking forward to forming successful business relationships with new clients around the world in the future.
Packing & Delivery
Unit Type: piece
Package Weight: 0.3kg
Package Size: 10cm x 10cm x 8cm
