Quick Details
-
Brand Name:
-
Tai De Ding Shun
-
Voltage:
-
350
-
Dimension(L*W*H):
-
2000*2200*2380MM
-
Weight (KG):
-
2500
-
Power (kW):
-
15
-
Applicable Industries:
-
Industry
-
Morkhench specificatior:
-
700*400MM
-
X/Y/Z Travel:
-
450*350*300MM
-
Maximum electrode load:
-
30KG
-
Maximum table load:
-
400KG
-
Machine Size (L*W*H):
-
2000*2200*2380MM
-
Maximum processing current:
-
75A
-
Appearance dimension:
-
550*1700*1850MM
-
Optimum surface finish/μm:
-
0.1
-
Maximum processing speed mm³/min:
-
800
-
Minimum electrode loss:
-
0.1%
Quick Details
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
Guangxi, China
-
Year:
-
2023
-
Brand Name:
-
Tai De Ding Shun
-
Voltage:
-
350
-
Dimension(L*W*H):
-
2000*2200*2380MM
-
Weight (KG):
-
2500
-
Power (kW):
-
15
-
Applicable Industries:
-
Industry
-
Morkhench specificatior:
-
700*400MM
-
X/Y/Z Travel:
-
450*350*300MM
-
Maximum electrode load:
-
30KG
-
Maximum table load:
-
400KG
-
Machine Size (L*W*H):
-
2000*2200*2380MM
-
Maximum processing current:
-
75A
-
Appearance dimension:
-
550*1700*1850MM
-
Optimum surface finish/μm:
-
0.1
-
Maximum processing speed mm³/min:
-
800
-
Minimum electrode loss:
-
0.1%
Specification
|
Specitication
|
Unit
|
CNC-B45S
|
|
X/Y/Z Travel
|
mm
|
450×350×300
|
|
Working oil tank volume
|
mm
|
900×640×410
|
|
Morkhench specificatior
|
mm
|
700×400
|
|
Distance from electrode head to workbench
|
mm
|
100-400
|
|
Maximum electrode load
|
kg
|
30
|
|
Maximum table load
|
kg
|
400
|
|
Machine Weigh
|
kg
|
2500
|
|
Machine Size (L*W*H)
|
mm
|
2000×2200×2380
|
|
Filter hox Size
|
Mm
|
1520×700×1150
|
|
tem
|
Unit
|
T750
|
|
Maximum processing current
|
A
|
75
|
|
Optimum surface finish
|
μm
|
0.1
|
|
Minimum electrode loss
|
%
|
0.1
|
|
Maximum processing speed
|
mm³/min
|
800
|
|
Net weigh
|
kg
|
350
|
|
Power
|
kw
|
15
|
|
Appearance dimension
|
mm
|
550×1700×1850
|
Features
★It can be connected to the robot electrode library
★The X,Y,and Z axes all adopt imported linear slide rails,Japanese Panasonic absolute servo motors,Taiwan Yintai or
Shangyin C-level screw rods,and German Rexroth P-level guide rails,which effectively guarantee the high precision of the machine
tool and the long-term durability of the machine tool.Stability and retention of accuracy in use,featuring high stiffness and high
sensitivity
★The column adopts a one-piece structure,which makes the B-axis more rigid,and the heavy-duty electrode processing can be done
easily
★Immersion processing is used to effectively guarantee the processing accuracy and surface finish
★The whole machine adopts centralized lubrication to provide uniform lubrication for each track surface.Smooth axial movement and
long-lasting precision
★Complete peripheral facilities such as automatic fire extinguishing device and processing fluid surface sensing device provide a
safe environment
★The fuselage is made of FC30 cast iron,after high temperature annealing and natural aging treatment
★The X,Y,and Z axes all adopt imported linear slide rails,Japanese Panasonic absolute servo motors,Taiwan Yintai or
Shangyin C-level screw rods,and German Rexroth P-level guide rails,which effectively guarantee the high precision of the machine
tool and the long-term durability of the machine tool.Stability and retention of accuracy in use,featuring high stiffness and high
sensitivity
★The column adopts a one-piece structure,which makes the B-axis more rigid,and the heavy-duty electrode processing can be done
easily
★Immersion processing is used to effectively guarantee the processing accuracy and surface finish
★The whole machine adopts centralized lubrication to provide uniform lubrication for each track surface.Smooth axial movement and
long-lasting precision
★Complete peripheral facilities such as automatic fire extinguishing device and processing fluid surface sensing device provide a
safe environment
★The fuselage is made of FC30 cast iron,after high temperature annealing and natural aging treatment
Product Description
Specification
|
Specification
|
Unit
|
CNC-400S
|
Standard Accessories
|
Optional Accessory
|
|
X/Y/Z Travel
|
mm
|
400*300*300
|
Three-axis linear slide
|
EROWA fixture
|
|
Oil Tank Working Fluid
|
mm
|
1050*650*350
|
Three-axis ball screw
|
C-axis
|
|
Table Size(L*W)
|
mm
|
700*400
|
Touch screen display+metal keyboard
|
pressure regulator
|
|
Distance between Electrode and Table
|
mm
|
100-400
|
Horizontal adjustment seat screw
|
Domestic fixture
|
|
Max.Load of Electrode
|
kg
|
50
|
Water spray claw and magnetic base
|
Fifth axis
|
|
Max.Load of Table
|
kg
|
450
|
Mots.WatW
|
Manloulator+electrode libran
|
|
Machine Weight
|
kg
|
3000
|
|
Dil coole
|
|
Machine Size (L*W*H)
|
mm
|
1850*2100*2380
|
Automatic Fire Extinguishe
|
|
|
Filter box size
|
mm
|
1760*1300*1120
|
Electrode collet
|
|
|
Maximum processing current
|
A
|
75A
|
Operating instructions
|
|
|
Power
|
kw
|
15
|
hold-all
|
|
|
Optimum surface finish
|
Ra
|
0.07μm
|
Detailed magnetic boa
|
|
|
Minimum electrode loss
|
|
0.10%
|
EDM fluic
|
|
|
Maximum processing speed
|
|
800mm³/min
|
hree-axis AC servo moto
|
|
|
Appearance dimension
|
|
550*1950*1950
|
|
|
Variety of other models
