Quick Details
-
conductance value:
-
20-19990S
-
voltage value:
-
0-25V
-
Storage capacity:
-
64M Bit Flash+ 4G card
-
Display:
-
5 Inch touch screen
Quick Details
-
Brand Name:
-
OREN
-
Place of Origin:
-
Shaanxi, China
-
Model Number:
-
OR-20
-
conductance value:
-
20-19990S
-
voltage value:
-
0-25V
-
Storage capacity:
-
64M Bit Flash+ 4G card
-
Display:
-
5 Inch touch screen
1. Online test battery voltage ,conductance and connecting strip resistance value
2. do battery capacity analysis , know the battery in good or bad condition quickly
3. Oscilloscope function: indicate the highest, lowest and average voltage
4. Building the history database, describe the battery life span curve.
5. Has comparison table for each battery in the same battery string.
6. All batteries are administrated by different SOH (excellent, good, medium and bad)
1. 5 Inch color touch screen
2. battery capacity testing range : 5AH-6000AH
3. Storage 99 9 group testing data
4. Storage 500 groups battery setting parameters
5. Use SD card , copy all testing data into PC
6. Use professional analysis software to generate testing report
|
MODEL |
OR-20 |
|
Testing Range |
Conductance :100~19,990S
|
|
Measurement Resolution |
Conductance: 1S
|
|
Precision |
Conductance:±0.5%rdg ±6dgt
|
|
Power Supply |
11.1V,2400mAh, rechargeable lithium |
|
Battery Life |
Work for 8 hours continuously |
|
Storage |
64Mbit Flash+ 4GSD |
|
Display |
5 Inch color touch LCD screen |
|
Size |
220 x 170 x 52mm |
|
Weight |
1.1Kg |
|
Humidity |
90% RH |
