Quick Details
-
Brand Name:
-
Bailey
-
Model Number:
-
bailey bridge HD200
Quick Details
-
Grade:
-
Q345B-Q460C
-
Tolerance:
-
±1%
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Bailey
-
Model Number:
-
bailey bridge HD200
|
ZB200 truss press limited table
|
|
|
|
|
|
|
|
|
|
|||||||||
|
No
|
internal force
|
structure form
|
|
|
|
|
|
|
|
|||||||||
|
|
|
not reinforced model
|
|
|
|
reinforced model
|
|
|
|
|||||||||
|
|
|
SS
|
DS
|
TS
|
QS
|
SSR
|
DSR
|
TSR
|
QSR
|
|||||||||
|
200
|
standard truss moment(kN.m)
|
1034.3
|
2027.2
|
2978.8
|
3930.3
|
2165.4
|
4244.2
|
6236.4
|
8228.6
|
|||||||||
|
200
|
standard
truss shear (kN)
|
222.1
|
435.3
|
639.6
|
843.9
|
222.1
|
435.3
|
639.6
|
843.9
|
|||||||||
|
201
|
high bending truss moment(kN.m)
|
1593.2
|
3122.8
|
4585.5
|
6054.3
|
3335.8
|
6538.2
|
9607.1
|
12676.1
|
|||||||||
|
202
|
high bending truss shear(kN)
|
348
|
696
|
1044
|
1392
|
348
|
696
|
1044
|
1392
|
|||||||||
|
203
|
Shear force of super high shear truss(kN)
|
509.8
|
999.2
|
1468.2
|
1937.2
|
509.8
|
999.2
|
1468.2
|
1937.2
|
|||||||||
|
ZB200 Table of geometric characteristics of truss bridge（Half bridge）
|
|
|
|
|
||||
|
structure
|
g
eometric characteristi
cs
|
|
|
|
||||
|
structure |
geometric characteristics
|
chord area(cm2)
|
Section properties（cm3）
|
Moment of inertia(cm
4
)
|
||||
|
ss
|
SS
|
25.48
|
5437
|
580174
|
||||
|
SS
|
SSR
|
50.96
|
10875
|
1160348
|
||||
|
DS
|
DS
|
50.96
|
10875
|
1160348
|
||||
|
|
DSR1
|
76.44
|
16312
|
1740522
|
||||
|
DS
|
DSR2
|
101.92
|
21750
|
2320696
|
||||
|
TS
|
TS
|
76.44
|
16312
|
1740522
|
||||
|
|
TSR2
|
127.4
|
27185
|
2900870
|
||||
|
TS
|
TSR3
|
152.88
|
32625
|
3481044
|
||||
|
QS
|
QS
|
101.92
|
21750
|
2320696
|
||||
|
|
QSR3
|
178.36
|
38059
|
4061218
|
||||
|
QS
|
QSR4
|
203.84
|
43500
|
4641392
|
||||
