- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
SEM9600
-
Product Name:
-
Automatic Weather Station
-
Digital output:
-
RS232,RS485,SDI-12
-
Power supply:
-
VDC: 7V-24V
-
IP protection:
-
IP65
-
Baut rate:
-
4800 - 19200
-
Communication:
-
ModBus-RTU,NMEA0183,SDI-12
-
Size:
-
84mm*(120-298)mm / 0.38kg
-
Material:
-
ASA engineering plastic
-
Function:
-
Weather Forecast
-
Key word:
-
super weather station
Quick Details
-
Warranty:
-
1 YEAR
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
SENTEC
-
Model Number:
-
SEM9600
-
Product Name:
-
Automatic Weather Station
-
Digital output:
-
RS232,RS485,SDI-12
-
Power supply:
-
VDC: 7V-24V
-
IP protection:
-
IP65
-
Baut rate:
-
4800 - 19200
-
Communication:
-
ModBus-RTU,NMEA0183,SDI-12
-
Size:
-
84mm*(120-298)mm / 0.38kg
-
Material:
-
ASA engineering plastic
-
Function:
-
Weather Forecast
-
Key word:
-
super weather station
SEMI9600 ultrasonic anemometer has advantage of light weigh, robust,no moving parts, free of
maintenance and calibration on site, simultaneously output wind speed and direction.
SEMI9600 can be connected to computer or any other data acquisition module which has compatible
communication protocol with it.
SEMI9600 has two communication interfaces for option, RS232 or RS485.
Product Specification
|
ITEMS
|
Range
|
Accuracy
|
Resolution
|
|
|
||||
|
Wind speed
|
0-70m /s
|
± 3%
|
0.1m/s
|
|
|
||||
|
Wind direction
|
0-359 °
|
±3 °
|
1 °
|
|
|
||||
|
Temperature
|
- 40 ℃ - + 80 ℃
|
± 0.5℃
|
0.1 ℃
|
|
|
||||
|
Humidity
|
0－100%
|
±3％
|
1
|
|
|
||||
|
Atmospheric pressure
|
150 － 1100hPa
|
±1hPa
|
0.1hPa
|
|
|
||||
|
Visibility
|
10-4000 meters
|
±15％
|
1 meter
|
|
|
||||
|
Noise
|
30-130 dB
|
±3dB
|
0.1dB
|
|
|
||||
|
Rainfall*
|
0-200mm/hr
|
±5％
|
0.01mm
|
|
|
||||
|
Altitude*
|
-500m ～ 9000m
|
±10％
|
1m
|
|
|
||||
|
Solar Radiation
|
0-2000 W/m2
|
±5％
|
0.1W/m2
|
|
|
||||
|
Luminance
|
0-200000lux
|
±5％
|
0.1 lux
|
|
|
||||
|
UV radiation*
|
0-2000 W/m2
|
±10％
|
0.1W/m2
|
|
|
||||
|
PM1.0/PM2.5/PM10(dust)*
|
0-500μg/m3
|
±5％
|
1μg/m3
|
|
|
||||
|
Digital output
|
RS232,RS485,SDI-12
|
|
|
|
|
||||
|
Power supply
|
VDC: 7V-24V
|
|
|
|
|
||||
|
Communication Protocol
|
ModBus-RTU,NMEA0183,SDI-12
|
|
|
|
|
||||
|
Output Frequency
|
1Hz
|
Protection Grade
|
IP65
|
|
|
||||
|
Baut rate
|
4800 - 19200
|
|
|
|
|
||||
|
Operating Environment
|
Temperature:-40℃ - +70℃; Humidity:0 - 100%
|
|
|
|
|
||||
|
Size
|
Φ110*297mm
|
|
|
|
|
||||
|
Material
|
ASA engineering plastic
|
|
|
|
|
||||
Shipping
FAQ
1. Could I have prices of your products?
Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours
2. Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
3. What's the lead time for regular order?
3~7 days for order quantity lower than 500pcs, For more quantity, usually 15 days.
4. Can I get a discount?
Yes, for the order quantity more than 50pcs, please contact us to get the best price.
5. What is your MOQ?
The MOQ of most of our products is 1PCS. You can also contact us to get a lower low MOQ.
6. How to contact you?
Email/Skype: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848446685
Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours
2. Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
3. What's the lead time for regular order?
3~7 days for order quantity lower than 500pcs, For more quantity, usually 15 days.
4. Can I get a discount?
Yes, for the order quantity more than 50pcs, please contact us to get the best price.
5. What is your MOQ?
The MOQ of most of our products is 1PCS. You can also contact us to get a lower low MOQ.
6. How to contact you?
Email/Skype: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848446685
As the specifications affect the price difference, page price for reference only. The final price is subject to our final
confirmation.
confirmation.
