Quick Details
-
Number of Cells:
-
32
-
Panel Dimensions:
-
480*665*24
-
Panel Efficiency:
-
>20%
-
Type:
-
220W Flexible Foldable Solar Panel
-
Solar cell:
-
Mono 210*35 Cell
-
Cable:
-
3m
-
Application:
-
Industrial, Home
-
OEM Order:
-
Acceptable
-
Material:
-
ETFE+ Special Material+Cell+ Backsheet
-
Weight:
-
4.5kgs
-
Advantage:
-
Powerful and Lightweight
-
Warranty:
-
1 Year
-
Waterproof:
-
IP67
Quick Details
-
Brand Name:
-
DOKIO
-
Model Number:
-
FFSP-220M
-
Place of Origin:
-
Zhejiang, China
-
Number of Cells:
-
32
-
Panel Dimensions:
-
480*665*24
-
Panel Efficiency:
-
>20%
-
Type:
-
220W Flexible Foldable Solar Panel
-
Solar cell:
-
Mono 210*35 Cell
-
Cable:
-
3m
-
Application:
-
Industrial, Home
-
OEM Order:
-
Acceptable
-
Material:
-
ETFE+ Special Material+Cell+ Backsheet
-
Weight:
-
4.5kgs
-
Advantage:
-
Powerful and Lightweight
-
Warranty:
-
1 Year
-
Waterproof:
-
IP67
Most of the panel have in stock in our Europe warehouse and American warehourse, we can ship to you within 3days after you ordered!!!
FREE SHIPPING FROM OVERSEA WAREHOUSE!!!
1. We have more than fifteen years of experience in manufacturing solar panels and have passed many international certifications. The product is safe and reliable.
2.High efficiency with quality silicon materials for long term output stability.
3.Foldable design, lightweight,portable and space saving,suitable for camping, hiking,and can be used as a backup power source for mobile phones and car batteries.
4.The controller uses USB connection, which can reduce the current consumption and guarantee the power.
5.The surface materials, which has the characteristics of corrosion resistance, high temperature resistance, high stain resistance and high light transmittance etc.
Recommend Products
All of the following Item have in Stock, Can Click the Link to Purchase, More than 10pcs, Welcome to send me message for
Discount
!
Specification
|
pv module
|
|
FFSP-220M
|
|
|
|||
|
Rated power (Pm)
|
|
220W±3%
|
|
|
|||
|
Typical application
|
|
12V DC
|
|
|
|||
|
Maximum voltage
|
|
600V DC
|
|
|
|||
|
Operating temperature
|
|
45°C
|
|
|
|||
|
Hail diameter @ 80Km/h
|
|
Up to 25 mm
|
|
|
|||
|
Continuous wind pressure
|
|
Up to 24 m/s
|
|
|
|||
|
Weight
|
|
4.5KGS
|
|
|
|||
|
Rated current (Im)
|
|
11.12A
|
|
|
|||
|
Rated voltage(Vm)
|
|
18V
|
|
|
|||
|
Short circuit Current(Isc)
|
|
11.36A
|
|
|
|||
|
Open circuit Voltage(Voc)
|
|
22.5V
|
|
|
|||
