Quick Details
-
Model Number:
-
HGN4-03
-
Max. Current:
-
max.25A
-
Product name:
-
DC ATS
-
IP Degree:
-
ip20
-
material:
-
PC + ABS
-
Installation method:
-
Panel mounting and rail mounting optional
-
application:
-
Solar power unit or station,FIXED INSIDE BOX
-
Certificate:
-
SAA
-
Standard:
-
IEC60947-3
-
Certification:
-
CE, CCC, TUV
Quick Details
-
Max. Voltage:
-
MAX.DC 1000V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Masterele/Adels/Thorsman
-
Model Number:
-
HGN4-03
-
Max. Current:
-
max.25A
-
Product name:
-
DC ATS
-
IP Degree:
-
ip20
-
material:
-
PC + ABS
-
Installation method:
-
Panel mounting and rail mounting optional
-
application:
-
Solar power unit or station,FIXED INSIDE BOX
-
Certificate:
-
SAA
-
Standard:
-
IEC60947-3
-
Certification:
-
CE, CCC, TUV
DC Auto Transfer Switch 1000V for Solar Photovoltauc System
Product Details
| Features : |
|
| Item | Description | |
| Standard | IEC 61439-1,IEC 61439-2,IEC 61439-3 | |
| Busbar rating | 100A and 225A | |
| Busbar type | ETP copper Tin plated flat fully shrouded | |
| Voltage rating | 110-415V AC 50/60 Hz | |
| No.of ways | 3PH:12,18,24,30,36,42 | |
| Degree of ways | IP40 | |
| Enclosure material | Electro-galvanized steed sheet(Corrosion resistant) | |
| Steel thickness | Up to 1.2mm | |
| Knockout sizes | See details on page 5 | |
| Enclosure colour | Polyseter powder coated in RAL-7035 light grey colour | |
| Paint thickness | 70-90 Minrons | |
| Main breaker(Incomer) | MCB & MCCB | |
| Terminal capacity | MCB frame size 100A | 50 sp.mm |
| MCCB frame size 100A | 50 sp.mm | |
| MCCB frame size 225A | 120 sp.mm | |
| Branches | 1,2&3 Pole plug-in MCBs | |
| Neutral terminal bar | Incoming cable lug | 100A-50 sq.mm |
| 225A-120 sq.mm | ||
| Outgoing terminals | 16 sq.mm | |
| No.of outgoing terminals | Equivalent or more than no.of ways | |
| Earth terminal bar | Incoming cable lug | 100A-225A-50 sq.mm |
| Outgoing terminals | 16 sq.mm | |
| No.of outgoing terminals | Equivalent or more than no.of ways | |
| Rated insulation voltage | 690V AC | |
| Ambient temperature | 50℃ | |
