Quick Details
-
Power:
-
19.6kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LOONGSHEEN
-
Maximum Digging Height:
-
3714
-
Maximum Digging Depth:
-
2150
-
Max Digging Radius:
-
4023
-
Rated Speed:
-
2.2
-
Warranty of core components:
-
1 year
-
Bagger Made In China:
-
MINI EXCAVATOR 2.5 ton
-
2.5 Ton Excavator:
-
CE Mini Excavator
-
Mini Excavator Crawler:
-
Customer's Required
-
Mini Excavator Prices:
-
Main parts 12months
-
TRACK WIDTH:
-
230mm
-
Bucket Width:
-
490mm
-
Rated power:
-
26.7HP
-
Swing speed:
-
12 Rpm
-
Chassis Width:
-
1200mm
-
Certification:
-
CE
Quick Details
-
Operating Weight:
-
2500KG
-
Bucket capacity:
-
0.08
-
Engine Brand:
-
Famous Brand
-
Power:
-
19.6kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LOONGSHEEN
-
Maximum Digging Height:
-
3714
-
Maximum Digging Depth:
-
2150
-
Max Digging Radius:
-
4023
-
Rated Speed:
-
2.2
-
Warranty of core components:
-
1 year
-
Bagger Made In China:
-
MINI EXCAVATOR 2.5 ton
-
2.5 Ton Excavator:
-
CE Mini Excavator
-
Mini Excavator Crawler:
-
Customer's Required
-
Mini Excavator Prices:
-
Main parts 12months
-
TRACK WIDTH:
-
230mm
-
Bucket Width:
-
490mm
-
Rated power:
-
26.7HP
-
Swing speed:
-
12 Rpm
-
Chassis Width:
-
1200mm
-
Certification:
-
CE
2.The mini excavator can attach hammer/ auger /ripper/ 350mm bucket /490mm bucket /600mm bucket / 800mm bucket /loader bucket /Quick hitch /grabber .
3.The mini excavator are smart and superior in performance, low in fuel consumption .
4.It is suitable to be used for small works, small projects, in garden, farmland, municipal works,vegetable greenhouse, digging trench .
5.The platform can rotate 360 degrees
|
Model |
LX25-9B |
|
Overall dimensions |
|
|
Total Length |
4082(mm) |
|
Total Height |
2128(mm) |
|
Total Width |
1200(mm) |
|
Operating Weight |
2500kg |
|
Ground Clearance |
458(mm) |
|
Ground Pressure |
38Kpa |
|
Performance |
|
|
Max. Digging Height |
3714(mm) |
|
Max.Dumping Height |
2488(mm) |
|
Max. Digging Depth |
2150(mm) |
|
Max. Digging Radius |
4023(mm) |
|
Swing Arm Deflection Angle (left/right) |
70°/50° |
|
Slewing Angle |
360° |
|
Grade Ability |
25° |
|
Travel Speed |
2.2km/h |
|
Bucket Volume |
0.08m3 |
|
Bucket Width |
490(mm) |
|
Engine |
|
|
Engine Type |
3TNV88 or Changchai |
|
Power |
19.6/2200 KW/rpm |
|
Pump |
|
|
Main Pump |
Triple Pump |
|
Main Pressure |
18(MPa) |
|
Max.RPM of the Pump |
2500 r/min |
|
Pump Displacement |
25 ml/r |
|
Track |
|
|
Track Gauge |
950(mm) |
|
Track Width |
230(mm) |
|
Track Length (on ground) |
1250(mm) |
Canopy and cab optional
One unit in wooden box
