Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VStarcam
-
Model Number:
-
CS58Q
-
Video Compression Format:
-
H.264+
-
audio:
-
Two-way audio
-
Operation system:
-
Embedded Linux OS
-
Compression Format:
-
H.265
-
Lens:
-
4.0mm
-
Support:
-
Max 256G TF/Micro SD Card
-
Video Compression:
-
IR Cut H.264 IP Camera
-
Certification:
-
ce, FCC, ROHS
-
Feature:
-
Support AI
-
Camera:
-
IP67 waterproof
Quick Details
-
Network:
-
wifi, ONVIF
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Special Features:
-
NIGHT VISION, Two-way Audio, Human Motion Tracking, Motion Detection, Sound Detection, Waterproof / Weatherproof
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VStarcam
-
Model Number:
-
CS58Q
-
Video Compression Format:
-
H.264+
-
audio:
-
Two-way audio
-
Operation system:
-
Embedded Linux OS
-
Compression Format:
-
H.265
-
Lens:
-
4.0mm
-
Support:
-
Max 256G TF/Micro SD Card
-
Video Compression:
-
IR Cut H.264 IP Camera
-
Certification:
-
ce, FCC, ROHS
-
Feature:
-
Support AI
-
Camera:
-
IP67 waterproof
Product Description
Product information
|
Sorts
|
Type
|
Parameters
|
|
System
|
Operating system
|
Embedded Linux
|
|
|
Online visitor
|
Supports 4 visitors at the same time
|
|
Collection
|
CPU/Image sensor
|
1/3 inch CMOS sensor
|
|
|
Minimum illumination
|
0.5 Lux(Color mode), 0.1 Lux(B&W mode)
|
|
|
Lens/Viewing angle
|
4mm@F2.1/90.9°Diagonal
|
|
|
Night Vision
|
IR-CUT with auto-switching, 4pcs 850nm IR LED lights, Irradiation distance 5~10 m
|
|
Video
|
Compression standard
|
H.264 main profile/Motion-JPEG/JPEG
|
|
|
Data rate
|
Main stream: 1296p(2304×1296)@25fps
|
|
|
|
Substream：360p(640×360)@25fps
|
|
|
Bit rate/maximum frame rate
|
128～4096kbps/25fps
|
|
|
Image adjustment
|
Brightness, contrast, saturation, chroma are adjustable
|
|
Audio
|
Input
|
Built-in－38dB microphone
|
|
|
Output
|
Built-in 8Ω1.5W speaker
|
|
|
Sampling frequency/bit width
|
8KHz/16bit
|
|
|
Compression standard/Bit Rate
|
G.711/32kbps
|
|
Network
|
Network interface
|
10Mbps/100Mbps self-adaptive/RJ45 Interface
|
|
|
Network protocol
|
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc.
|
|
|
Wireless network
|
IEEE802.11b/g/n
|
|
|
Wireless frequency
|
2.4GHz
|
|
|
Wireless security encryption
|
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
|
|
Storage
|
Storage functions
|
Support T-Flashcard(max256GB); Cloud storage;
|
|
Alarm
|
Alarm detection
|
Supports Motion detection; Humanoid detection; Humanoid tracking; Absences alarm;
|
|
Physical Indicators
|
Rated voltage
|
DC12V±5%
|
|
|
Power consumption
|
Rated power: 3.8 W(with IR LED lights ON)/ Max Power:5W
|
|
|
Operating condition
|
Temperature: -10～50℃; Humidity: ＜90%
|
|
|
Weight
|
N.W.: 335g（Note: in kind prevail）
|
|
|
Packaging Size
|
228x149x93mm (LxWxH)
|
