638 Cylindrical bonding sealant,High Strength Retaining Compound glue

638 Cylindrical bonding sealant,High Strength Retaining Compound glue

FOB Reference Price: Get Latest Price

≥100 Pieces

US $0.38

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

EINECS No.:: 230-391-5

Place of Origin:: Shanghai, China

Brand Name:: ND

Model Number:: ND638

Type:: One Componet

NAME:: High Strength Retaining Compound

Material:: Polyuerthane

Feature:: Eco-friendly

Packing:: Bottle

Certificate:: MSDS RoHS

Advantage:: Strong Adhestion

OEM:: Allowed

Curing time:: Tensile Shear strength after 48 hours at 20° to 25°C

Quick Details

CAS No.:: 7085-85-0

Other Names:: Super Glue

MF:: C50H94O24

EINECS No.:: 230-391-5

Place of Origin:: Shanghai, China

Brand Name:: ND

Model Number:: ND638

Type:: One Componet

NAME:: High Strength Retaining Compound

Material:: Polyuerthane

Feature:: Eco-friendly

Packing:: Bottle

Certificate:: MSDS RoHS

Advantage:: Strong Adhestion

OEM:: Allowed

Curing time:: Tensile Shear strength after 48 hours at 20° to 25°C

Product Description

anaerobic Adhesive .

638 High Strength Retaining Compound
is a single part, medium viscosity, high strength REnaerobic resin used for bonding rigid assemblies of all types. This material can be used effectively to increase the strength of most mechanical assemblies

Typical Applications

Vibra-Tite 638 can be used in a broad variety of applications such as:
 Locking keys and splines
 Eliminating backlash in worn assemblies
 Locking bearings in place, preventing spin
out
 Bonding rotor to shaft in low horsepower
motors
 Locking bushings and sleeves in housings
and on shafts
 Restoring the fit to worn assemblies or outof tolerance pans

Instructions for Use
Ensure parts are clean, dry and free from oil and grease.
Procedure for Application
Product is normally hand applied from the bottle onto parts.

Product Paramenters

Technical Features
Properties of Uncured Material
Chemical Type Anaerobic
Appearance Green
Toxicity Low
Solids 100%
Viscosity @ 25ºC, cP
Brookfield RVT,
Spindle 5 @ 20 rpm 5000 to 10000

Specific Gravity 1.16
Performance of Cured Material
Typical Values
Fixture Time 15-20 min@72oF
Full Cure Time 24 hrs @ 72oF
Temperature Range -60oF to 350oF
(-51oC to 177oC)
Shear Strength
After 24 hour cure
Steel pins and collars >2500 psi

After 24 hr cure, 24 hrs at 177oC, tested at 22 oC Steel pins and collars >3500 psi

Environmental and Fluid Resistance
(Shear strength values)
Typical Values
Heat age 105%
Engine oil@ 150oC 98%
Brake fluid @ 150oC 100%
ATF @ 150oC 80%
50/50 water/
ethylene glycol @ 120oC 80%
Water @ 100oC 80%
Gasoline @ 25oC 100%
Diesel fuel @ 25oC 100%
Ethyl Alcohol @25oC 95%

General Information

Storage
Product should be stored in a cool and dry location at
temperatures between 14°F (-10°C) to 86°F (30°C).
Shelf life is 2 years from date of manufacture when
stored at 72±8°F (22±4°C).
Note
Where gap size is large or where the surface is
uneven, apply a Vibra-TITE primer to help cure the
product through volume. Gasket Maker can be roller
coated, screen printed or applied by pads.
Health & Safety in use
IRRITANT: Contains Methacrylate Esters which
may irritate eyes, respiratory organs and skin. In
case of contact with the skin, wash immediately
with plenty of water.

Manufacturing Technique

638 anaerobic Adhesive is a high temperature, high strength,
anaerobic retaining compound designed for metal cylindrical assembly applications

Sheer strength on steel after 12 month soak

For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS)

Application

Recommend Products

Packing & Delivery

anaerobic Adhesive Gasket Maker is a single component, medium strength, thixotropic, anaerobic sealant ......... tube .50ml, 250ml and liter (bottle)

Spec 2ml 10ml 50ml 250ml 1L (Drums packing) Package 24pcs/ctn 24pcs/ctn 24pcs/ctn Silver Paper Bag

packing :

20GP Container Load 2200 ctns 2050 ctns 2050 ctns 72 drums High temperature silicone seal waterproof transparent silicone sealant
Delivery Time
15 -35 days upon the receipt of the down payment

FAQ

Q: Are you trading company or manufacturer ?
A: We are manufacturer

Q: How long is your delivery time?
A: Generally it is 5-7 days if the goods are in stock. and it is 15-35 days if the goods are not in stock, it is also according to
quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the free sample but exclued freight, kindly noted.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
